Home Wenglor Inductive Sensor Inductive Sensor Series I1DH004 Wenglor I1DH004 Inductive Sensor The Wenglor I1DH004 Inductive Sensor offers 10 mm switching distance, Non-flush mounting, 10 ... 30 V DC supply voltage, 460 Hz switching frequency. Manufactured by Wenglor under the Wenglor Inductive Sensor category, this model belongs to the Wenglor Inductive Series .
Brand Wenglor Product Type Inductive Sensor Model Number I1DH004
Wenglor I1DH004 Inductive Sensor – Technical Specifications Specification Value Switching Distance 10 mm Correction Factors Stainless Steel V2A/CuZn/Al 1,06/0,56/0,52 Mounting Non-flush Mounting A/B/C/D in mm 72/14/30/10 Mounting B1 in mm 0...12 Switching Hysteresis < 10 % Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 10 mA Switching Frequency 460 Hz Temperature Drift < 10 % Temperature Range -40 ... 80 °C Switching Output Voltage Drop < 1 V Switching Output/Switching Current 150 mA Residual Current Switching Output 100 µA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Protection Class III Housing Material Plastic, PBT Sensing face Plastic, PBT Degree of Protection IP67
IP68 Connection M8 × 1; 3-pin Weight 20 g MTTFd (EN ISO 13849-1) 3,706.54 a Packaging unit 1 Piece Error Indicator yes PNP NC yes
