Wenglor FRS03-2M-05 Photoelectric Sensor

Name: Wenglor FRS03-2M-05
Brand: Wenglor
SKU: FRS03-2M-05
Rating: 4.3 (4 reviews)

The Wenglor FRS03-2M-05 Photoelectric Sensor offers 0.5 mm fiber core diameter, -40 ... 70 °C temperature range, 15 mm bending radius, Plastic, PMMA fiber optic material. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Fiber-Optic Cables Series.

Datasheet

Brand	Wenglor
Product Type	Fiber-Optic Sensors
Model Number	FRS03-2M-05

Wenglor FRS03-2M-05 Photoelectric Sensor – Technical Specifications

Specification	Value
Fiber Core Diameter	0.5 mm
Fiber	Step Index
Fiber Distribution	parallel arrangement
Detection range with P1XD0xx	40 mm
Detection range P1XD10x/11x	60 mm
Detection range P1XD12x/13x	50 mm
Detection range P1XD2xx red light	60 mm
Detection range P1XD2xx blue light	40 mm
Detection range P1XD2xx pink light	70 mm
Opening Angle	55 °
Cable type	Standard
Temperature Range	-40 ... 70 °C
Bending Radius	15 mm
Fiber-Optic Length L	2 m
Jacket Material	Plastic, PE
Fiber Optic Material	Plastic, PMMA
Material End Sleeve	Stainless steel, V2A (1.4305 / 303)
Jacket Diameter	1 mm
Light Emission	straight
Weight	10 g
Packaging unit	1 Piece
