Wenglor FRF02-2M-10 Photoelectric Sensor

Name: Wenglor FRF02-2M-10
Brand: Wenglor
SKU: FRF02-2M-10
Rating: 4 (4 reviews)

The Wenglor FRF02-2M-10 Photoelectric Sensor offers 1 mm fiber core diameter, -40 ... 70 °C temperature range, 20 mm bending radius, Plastic, PMMA fiber optic material. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Fiber-Optic Cables Series.

Datasheet

Brand	Wenglor
Product Type	Fiber-Optic Sensors
Model Number	FRF02-2M-10

Wenglor FRF02-2M-10 Photoelectric Sensor – Technical Specifications

Specification	Value
Fiber Core Diameter	1 mm
Fiber	Step Index
Fiber Distribution	parallel arrangement
Detection range with P1XD0xx	75 mm
Detection range P1XD10x/11x	90 mm
Detection range P1XD12x/13x	85 mm
Detection range P1XD2xx red light	75 mm
Detection range P1XD2xx blue light	95 mm
Detection range P1XD2xx pink light	120 mm
Opening Angle	55 °
Cable type	Standard
Temperature Range	-40 ... 70 °C
Bending Radius	20 mm
Fiber-Optic Length L	2 m
Jacket Material	Plastic, PE
Fiber Optic Material	Plastic, PMMA
End sleeve shape	Flat
Material End Sleeve	Stainless steel, V2A (1.4305 / 303)
Jacket Diameter	2.2 mm
Light Emission	sidewise
Weight	20 g
Packaging unit	1 Piece
