Home Wenglor Photoelectric Sensors Through-Beam Sensors EW98PC3 Wenglor EW98PC3 Photoelectric Sensor The Wenglor EW98PC3 Photoelectric Sensor offers 10,000 mm range, Receiver sensor type, 10 ... 30 V DC supply voltage, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Through-Beam Series .
Brand Wenglor Product Type Through-Beam Sensors Model Number EW98PC3
Wenglor EW98PC3 Photoelectric Sensor – Technical Specifications Specification Value Range 10,000 mm Light Source Red Light Service Life (T = +25 °C) 100,000 h Sensor Type Receiver Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 40 mA Temperature Drift < 10 % Temperature Range -10 ... 60 °C Reverse Polarity Protection yes Protection Class III Housing Material Stainless steel, V2A (1.4305 / 303)
Plastic, PBT Degree of Protection IP67 Connection M12 × 1; 4-pin Weight 41 g Switching Hysteresis < 15 % Max. Ambient Light 10,000 Lux Switching Frequency 150 Hz Response Time 3,300 µs Switching Output Voltage Drop < 2.5 V Residual Current Switching Output < 50 µA Short Circuit Protection yes Overload Protection yes Setting Method Potentiometer PNP NO yes Opening Angle 6 ° Full Encapsulation yes PNP Switching Output/Switching Current 200 mA
