Home Wenglor Photoelectric Sensors Through-Beam Sensors E1FL66VD Wenglor E1FL66VD Photoelectric Sensor The Wenglor E1FL66VD Photoelectric Sensor offers 1,000 mm range, Receiver sensor type, 10 ... 30 V DC supply voltage, IP67 degree of protection. Manufactured by Wenglor under the Wenglor Photoelectric Sensor category, this model belongs to the Wenglor Through-Beam Series .
Brand Wenglor Product Type Through-Beam Sensors Model Number E1FL66VD
Wenglor E1FL66VD Photoelectric Sensor – Technical Specifications Specification Value Range 1,000 mm Light Source Infrared Light Service Life (T = +25 °C) 100,000 h Sensor Type Receiver Supply Voltage 10 ... 30 V DC Current Consumption (Ub = 24 V) < 30 mA Temperature Drift < 10 % Temperature Range -25 ... 60 °C Reverse Polarity Protection yes Protection Class III Housing Material Plastic, ABS/GF Degree of Protection IP67 Connection Cable; 3-wire Weight 21 g MTTFd (EN ISO 13849-1) 5,592.92 a Switching Hysteresis < 15 % Max. Ambient Light 10,000 Lux Switching Frequency 500 Hz Response Time 1 ms Switching Output Voltage Drop < 2.5 V Switching Output/Switching Current 100 mA Residual Current Switching Output < 50 µA Short Circuit Protection yes Overload Protection yes PNP NC yes Opening Angle 30 ° Cable Length (L) 2 m Cable Jacket Material PVC
