IR-DQ08-R - Weintek Digital IO Module
IR-DQ08-R Weintek Digital IO Module
| Brand | Weintek |
| Product Type | IO Module |
| Product | IR-DQ08-R |
Weintek Digital IO Module IR-DQ08-R Technical Specifications:
| Specification | Value |
|---|
| Number of Outputs | 8 |
| Output Type | Relay |
| Current Consumption | 220mA@5VDC |
| Output Voltage | 250VAC/30VDC |
| Output Current | 2A per channel (Max 8A) |
| Response Time (OFF->ON / ON->OFF) | 300μs / 10μs |
| Isolation (Output) | Electromagnetic Isolation |
| PCB Coating | No |
| Enclosure | Plastic |
| Dimensions (W x H x D mm) | 27 x 109 x 81 mm |
| Mount | 35mm DIN rail mounting |
| Protection Structure | IP20 |
| Storage Temperature | -20° ~ 70°C |
| Operating Temperature | 0° ~ 55°C |
| Relative Humidity | 10% ~ 90% (non-condensing) |
| Altitude (Air Pressure) | Below 3000 m |
| Weight | Approx. 0.13 kg |
