PRO PM 250W 12V 21A: 2660200291 - Weidmuller 12 Volt Switch Mode Power Supply
Technical Specifications of Weidmuller 12 Volt Switch Mode Power Supply PRO PM 250W 12V 21A 2660200291:
| Spec | Value |
|---|---|
| Connection system | Screw connection |
| Frequency range AC | 47...63 Hz |
| Rated Current | 21 A |
| Output power | 250 W |
Weidmuller 12 Volt Switch Mode Power Supply PRO PM 250W 12V 21A, 2660200291 Technical Specifications:
| Specification | Value |
|---|---|
| Depth | 215 mm |
| Height | 30 mm |
| Width | 115 mm |
| AC input voltage range | 90…264 V AC |
| Connection system | Screw connection |
| DC input voltage range | - |
| Frequency range AC | 47...63 Hz |
| Rated input voltage | 100...240 V AC |
| Surge protection | 13.5...16.2 V @ 12 V DC |
| Rated output current | 21 A |
| Output power | 250 W |
| Output voltage, max. | - |
| Output voltage, min. | - |
| Rated output voltage | 12 V DC |
| Protection degree | IP20 |
| Wire connection method | Screw connection |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -20 °C...70 °C |
| Weight | 736 g |
Get A Quote for Weidmuller 12 Volt Switch Mode Power Supply PRO PM 250W 12V 21A Order no: 2660200291 at unbeatable prices. Detailed Specifications of PRO PM 250W 12V 21A, 2660200291 feature 215 mm depth, 30 mm height, 115 mm width, 90…264 V AC input voltage, 47...63 Hz frequency, Screw connection, 100...240 V AC rated input voltage, 12 V DC rated output voltage, 21 A current, 250 W output power, IP20 degree of protection. Match Your Needs with a Quote for your requirement of Weidmuller 12 Volt Switch Mode Power Supply. Our pricing and support are unrivaled, especially when compared to other Distributors.
