Telemecanique ZCKS8: Standard Limit Switches Classic range
Technical Specifications of Telemecanique Standard Limit Switches Classic range ZCKS8:
| Product or component type | Limit switch body |
| Cable entry | 1 entry tapped for Pg 13.5 cable gland |
| Contacts type and composition | 2 NO |
| Contact operation | Slow-break, simultaneous |
Telemecanique Standard Limit Switches Classic range ZCKS8 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Limit switches XC Standard |
| Series name | Standard format |
| Product or component type | Limit switch body |
| Device short name | ZCKS |
| Body type | Fixed |
| Head type | - |
| Material | - |
| Body material | Plastic |
| Fixing mode | - |
| Movement of operating head | - |
| Type of operator | - |
| Type of approach | - |
| Cable entry | 1 entry tapped for Pg 13.5 cable gland |
| Contacts type and composition | 2 NO |
| Contact operation | Slow-break, simultaneous |
| Switch actuation | - |
| Electrical connection | Screw-clamp terminals, clamping capacity: 1 x 0.5...2 x 2.5 mm² |
| Contacts insulation form | - |
| Positive opening | Without |
| Contact code designation | - |
| Resistance across terminals | 0.25 mOhm conforming to IEC 60255-7 category 3 |
| Terminals description ISO n°1 | (13-14)NO |
| Shock resistance | - |
| Vibration resistance | - |
| IP degree of protection | IP65 |
| IK degree of protection | IK03 |
| Electrical shock protection class | - |
| Protective treatment | - |
| Standards | - |
| Product certifications | - |
| Repeat accuracy | - |
| Product specific application | - |
| Head material | - |
| Contact block per direction [control circuit] | - |
| Sensor design | - |
| Overvoltage category | - |
| Product compatibility | XCKS |
| Contacts material | Silver plated contacts |
| Environmental characteristic | Standard environment |
| Local display | - |
