Telemecanique XY2CH14270TK: Emergency Stop Rope Pull Switch
Technical Specifications of Telemecanique Emergency Push Button XY2CH14270TK
| Product or component type | - |
| Contacts type and composition | - |
| IP degree of protection | IP66 conforming to IEC 60529 |
| Body material | - |
Telemecanique Emergency Stop Rope Pull Switch XY2CH14270TK Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Emergency stop rope pull switches XY2C |
| Product or component type | - |
| Device short name | XY2CH |
| Housing colour | - |
| Overvoltage category | Class I conforming to EN/IEC 61140, class I conforming to NF C 20-030 |
| Local signalling | - |
| Body material | - |
| Cover material | - |
| Reset | - |
| Contacts type and composition | - |
| Contact operation | - |
| Trigger cable anchor point | - |
| Connections - terminals | - |
| Safety level | Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508 |
| Safety reliability data | B10d = 4000000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear |
| Marking | CE |
| Positive opening | - |
| Resistance across terminals | - |
| Terminals description ISO nΒ°1 | - |
| Standards | - |
| Product certifications | CCC category NISD emergency stop devices, CE |
| Protective treatment | TC |
| Vibration resistance | 10 gn (f= 10-300 Hz) conforming to EN/IEC 60068-2-6 |
| Shock resistance | 50 gn 11 ms conforming to EN/IEC 60068-2-27 |
| IP degree of protection | IP66 conforming to IEC 60529 |
| Compatibility code | - |
