Telemecanique XUVH0312: Photoelectric Sensors
Technical Specifications of Telemecanique Photoelectric Sensor XUVH0312:
| Sensor Design | Fork |
| Detection System | Thru beam |
| Discrete Output Type | PNP |
| Electrical Connection | Cable |
Telemecanique Photoelectric Sensors XUVH0312 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Photoelectric sensors XU |
| Series name | Application material handling |
| Electronic sensor type | Photo-electric sensor |
| Sensor name | XUV |
| Sensor design | Fork |
| Detection system | Thru beam |
| Material | Plastic |
| Supply circuit type | DC |
| Wiring technique | 3-wire |
| Discrete output type | PNP |
| Discrete output function | 1 NO |
| Electrical connection | Cable |
| Product specific application | Detection of flags in lifts/transtockers |
| Enclosure material | ABS/PC |
| Type of output signal | Discrete |
| Output type | Solid state |
| Voltage drop | - |
| Current consumption | <= 20 mA no-load |
| Vibration resistance | 7 gn, amplitude = +/- 1 mm (f = 10-42 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 30 gn (duration = 11 ms) conforming to IEC 60068-2-27 |
| Type of setting | - |
| Setting-up | Without sensitivity adjustment |
| Lens material | PMMA |
| Accuracy | - |
| Label length | - |
| Distance between labels | - |
| Passing speed of object | - |
| Delay first up | 30.0000 MILLISECOND |
| Delay response | 0.5000 MILLISECOND |
| Delay recovery | - |
| Add on output | - |
| Time delay range | - |
| Cable composition | 3 x 0.34 mm² |
| Keypad type | - |
| Switching frequency | - |
| Product certifications | - |
Ask for the Pricing of Photoelectric Sensors XUVH0312 at unbeatable prices. Detailed Specifications of XUVH0312 features Photo-electric sensor, Electronic sensor type for Application material handling Series name applications at competitive prices. Featuring a Fork design and a reliable Thru beam detection system, this sensor ensures precise detection in automation environments. Built from Plastic materials, it combines durability and lightweight performance, ideal for demanding industrial use. Operating with a DC supply circuit and a 3-wire wiring technique, it provides a PNP discrete output type and supports a 1 NO discrete output function, offering versatility in integration with control systems. Encased in a robust ABS/PC, this sensor is designed for durability in challenging environments. Specially engineered for Detection of flags in lifts/transtockers, it outputs a Discrete signal with a Solid state output type. Now's the Time to Secure a Quote for your requirement of Photoelectric Sensors. We're committed to offering more favorable pricing and more responsive support than other Traders.
