XSDA500519TF: Telemecanique XSD Series, 80 x 80 x 40 Inductive Sensors

Technical Specifications of Telemecanique XSD Series, 80 x 80 x 40 Inductive Sensors XSDA500519TF:

Sensor Design	Form 80 x 80 x 40
Wiring Technique	2-wire
Discrete Output Type	-
Electrical Connection	Screw-clamp terminals

Telemecanique XSD Series, 80 x 80 x 40 Inductive Sensors XSDA500519TF Technical Specifications

Specification	Value
Range of product	Telemecanique Inductive proximity sensors XS
Series name	General purpose
Sensor type	Inductive proximity sensor
Sensor name	XSD
Sensor design	Form 80 x 80 x 40
Size	40 mm
Body type	Fixed
Type of output signal	Discrete
Wiring technique	2-wire
Discrete output function	1 NO or 1 NC Programmable
Detector Flush mounting acceptance	Non Flush Mountable
Discrete output type	-
Material	Plastic
Electrical connection	Screw-clamp terminals
[Us] rated supply voltage	12...240 V AC
Output circuit type	AC
Switching capacity in mA	-
IP degree of protection	IP67
Enclosure material	Plastic
Detection face	5 Positions Turret Head
Front material	Plastic
Differential travel	-
Cable composition	-
Status LED	-
Wire insulation material	-
Switching frequency	<= 10 Hz
Voltage drop	-
Current consumption	-
Delay first up	-
Delay response	-
Marking	-
Delay recovery	-
Product certifications	CCC
Vibration resistance	-
Shock resistance	-
Thread type	-

Obtain a Quote for Telemecanique XSD Series, 80 x 80 x 40 Inductive Sensors XSDA500519TF with exclusive offers. Core System Specifications of XSDA500519TF feature Inductive proximity sensor, featuring an Form 80 x 80 x 40 design. This sensor operates with an Discrete Type of output signal, 1 NO or 1 NC Programmable output, designed for efficient and reliable performance in automation tasks. Rated for 12...240 V AC, ensuring durability in varying power conditions it promises safe and stable operation. Its IP67, IP degree of protection makes it suitable for challenging environments. Built from durable Plastic, this sensor is designed with an 5 Positions Turret Head detection face and can operate at a switching frequency of up to <= 10 Hz. Initiate Your Journey with a Quote for your requirement of Telemecanique XSD Series, 80 x 80 x 40 Inductive Sensors. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
