XS9C4A2A2P20: Telemecanique 40 x 40 x 117, 117 mm Length, DC Proximity Sensors

Technical Specifications of Telemecanique 40 x 40 x 117, 117 mm Length, DC Proximity Sensors XS9C4A2A2P20:

Sensor Design	Form 40 X 40 X 117
Wiring Technique	2 Wire
Discrete Output Type	-
Electrical Connection	Screw-clamp terminals, 4 x 1.5 mm²

Telemecanique 40 x 40 x 117, 117 mm Length, DC Proximity Sensors XS9C4A2A2P20 Technical Specifications

Specification	Value
Range of product	TE INDTIVE PROX SSRS XS
Series name	GENERAL PURPOSE
Sensor type	INDUCTIVE PROXIMITY SENSOR
Sensor name	XS9
Sensor design	Form 40 X 40 X 117
Size	117 mm
Body type	Fixed
Type of output signal	ANALOGUE
Wiring technique	2 Wire
Discrete output function	-
Detector Flush mounting acceptance	Non Flush Mountable
Discrete output type	-
Material	Plastic
Electrical connection	Screw-clamp terminals, 4 x 1.5 mm²
[Us] rated supply voltage	12...24 V DC with reverse polarity protection
Output circuit type	DC
Switching capacity in mA	-
IP degree of protection	IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050
Enclosure material	PBT
Detection face	5 Positions Turret Head
Front material	PBT
Differential travel	-
Cable composition	-
Status LED	Output state: 1 LED (yellow)
Wire insulation material	-
Switching frequency	-
Voltage drop	-
Current consumption	0...4 mA no-load
Delay first up	7.5000 MILLISECOND
Delay response	6.0000 MILLISECOND
Marking	CE
Delay recovery	6.0000 MILLISECOND
Product certifications	CSA UL
Vibration resistance	25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6
Shock resistance	50 gn for 11 ms conForming to EN 60068-2-27
Thread type	-

Ask for the Pricing of Telemecanique 40 x 40 x 117, 117 mm Length, DC Proximity Sensors XS9C4A2A2P20 at unbeatable prices. Detailed Specifications of XS9C4A2A2P20 features INDUCTIVE PROXIMITY SENSOR, featuring an Form 40 X 40 X 117 design. This sensor operates with an ANALOGUE Type of output signal, designed for efficient and reliable performance in automation tasks. Rated for 12...24 V DC with reverse polarity protection, ensuring durability in varying power conditions, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an 5 Positions Turret Head detection face and can operate. Now's the Time to Secure a Quote for your requirement of Telemecanique 40 x 40 x 117, 117 mm Length, DC Proximity Sensors. We're committed to offering more favorable pricing and more responsive support than other Traders.
