During technical comparisons, TELEMECANIQUESENSORS-XS9C2A2A2M12 appears alongside Telemecanique Limit Switch, Telemecanique Telemecaniquesensors Xs612B1Mal2 and Telemecanique Safety Interlock Switches Accessories so engineers assess signal types, ingress protection, and ambient tolerances accurately.
XS9C2A2A2M12: Telemecanique 40 x 40 x 70, 70 mm Length, Analogue Inductive Sensors
Technical Specifications of Telemecanique 40 x 40 x 70, 70 mm Length, Analogue Inductive Sensors XS9C2A2A2M12:
| Sensor Design | Form 40 X 40 X 70 |
| Wiring Technique | 2 Wire |
| Discrete Output Type | - |
| Electrical Connection | Male connector M12, 4 pins |
Telemecanique 40 x 40 x 70, 70 mm Length, Analogue Inductive Sensors XS9C2A2A2M12 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | - |
| Series name | GENERAL PURPOSE |
| Sensor type | INDUCTIVE PROXIMITY SENSOR |
| Sensor name | XS9 |
| Sensor design | Form 40 X 40 X 70 |
| Size | 70 mm |
| Body type | Fixed |
| Type of output signal | ANALOGUE |
| Wiring technique | 2 Wire |
| Discrete output function | - |
| Detector Flush mounting acceptance | Non Flush Mountable |
| Discrete output type | - |
| Material | Plastic |
| Electrical connection | Male connector M12, 4 pins |
| [Us] rated supply voltage | 12...24 V DC with reverse polarity protection |
| Output circuit type | DC |
| Switching capacity in mA | - |
| IP degree of protection | IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050 |
| Enclosure material | PBT |
| Detection face | 5 Positions Turret Head |
| Front material | PBT |
| Differential travel | - |
| Cable composition | - |
| Status LED | Output state: 1 LED (yellow) |
| Wire insulation material | - |
| Switching frequency | - |
| Voltage drop | - |
| Current consumption | 0...4 mA no-load |
| Delay first up | 7.5000 MILLISECOND |
| Delay response | 6.0000 MILLISECOND |
| Marking | CE |
| Delay recovery | 6.0000 MILLISECOND |
| Product certifications | CSA UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
| Thread type | - |
Call us for Telemecanique 40 x 40 x 70, 70 mm Length, Analogue Inductive Sensors XS9C2A2A2M12 at the lowest pricing. In-depth Technical Analysis of XS9C2A2A2M12 feature INDUCTIVE PROXIMITY SENSOR, featuring an Form 40 X 40 X 70 design. This sensor operates with an ANALOGUE Type of output signal, designed for efficient and reliable performance in automation tasks. Rated for 12...24 V DC with reverse polarity protection, ensuring durability in varying power conditions it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an 5 Positions Turret Head detection face and can operate. Capture the Best Deal with a Quote for your requirement of Telemecanique 40 x 40 x 70, 70 mm Length, Analogue Inductive Sensors. Our promise: More affordable pricing and more personalized support than other Dealers.
