Before procurement teams confirm TELEMECANIQUESENSORS-XS8C2A4MAU20, they typically review Telemecanique Limit Switch, Telemecanique Telemecaniquesensors Xs612B1Mal2 and Telemecanique Safety Interlock Switches Accessories to double-check performance ratings, stock availability, and supplier credibility carefully.
XS8C2A4MAU20: Telemecanique 40 x 40 x 70, 70 mm Length, 2 wire Proximity Sensors
Technical Specifications of Telemecanique 40 x 40 x 70, 70 mm Length, 2 wire Proximity Sensors XS8C2A4MAU20:
| Sensor Design | Form 40 X 40 X 70 |
| Wiring Technique | 2 Wire |
| Discrete Output Type | - |
| Electrical Connection | Male connector 1/2"20 UNF, 3 pins |
Telemecanique 40 x 40 x 70, 70 mm Length, 2 wire Proximity Sensors XS8C2A4MAU20 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | TE INDTIVE PROX SSRS XS |
| Series name | GENERAL PURPOSE |
| Sensor type | INDUCTIVE PROXIMITY SENSOR |
| Sensor name | XS8 |
| Sensor design | Form 40 X 40 X 70 |
| Size | 70 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 2 Wire |
| Discrete output function | 1 NO |
| Detector Flush mounting acceptance | Non Flush Mountable |
| Discrete output type | - |
| Material | Plastic |
| Electrical connection | Male connector 1/2"20 UNF, 3 pins |
| [Us] rated supply voltage | 24...240 V AC 50/60 Hz, 24...240 V DC |
| Output circuit type | AC DC |
| Switching capacity in mA | 5...200 mA DC, 5...300 mA AC |
| IP degree of protection | IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050 |
| Enclosure material | PBT |
| Detection face | 5 Positions Turret Head |
| Front material | PBT |
| Differential travel | 3 15 PT OF SR |
| Cable composition | - |
| Status LED | Supply on: 1 LED (green), output state: 1 LED (yellow) |
| Wire insulation material | - |
| Switching frequency | <= 25 Hz AC, <= 50 Hz DC |
| Voltage drop | <5.5 V (closed) |
| Current consumption | - |
| Delay first up | 7.5000 MILLISECOND |
| Delay response | 1.4000 MILLISECOND |
| Marking | CE |
| Delay recovery | 2.5000 MILLISECOND |
| Product certifications | CCC CSA UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to EN 60068-2-27 |
| Thread type | - |
IndMALL Automation Dealing offers Telemecanique 40 x 40 x 70, 70 mm Length, 2 wire Proximity Sensors XS8C2A4MAU20 at attractive prices. Key Technical Features of XS8C2A4MAU20 are INDUCTIVE PROXIMITY SENSOR, featuring an Form 40 X 40 X 70 design. This sensor operates with an Discrete Type of output signal, 1 NO output, designed for efficient and reliable performance in automation tasks. Rated for 24...240 V AC 50/60 Hz,
24...240 V DC, ensuring durability in varying power conditions. With a switching capacity up to 5...200 mA DC, 5...300 mA AC, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an 5 Positions Turret Head detection face and can operate at a switching frequency of up to <= 25 Hz AC,
<= 50 Hz DC. Navigate Your Needs with a Quote for your requirement of Telemecanique 40 x 40 x 70, 70 mm Length, 2 wire Proximity Sensors. We excel in offering more cost-effective and supportive solutions than other Competitors.
