XS8C2A4DAM12: Telemecanique 40 x 40 x 70, 70 mm Length, 1 NO Proximity Sensors
Technical Specifications of Telemecanique 40 x 40 x 70, 70 mm Length, 1 NO Proximity Sensors XS8C2A4DAM12:
| Sensor Design | Form 40 X 40 X 70 |
| Wiring Technique | 2 Wire |
| Discrete Output Type | - |
| Electrical Connection | Male connector M12, 4 pins |
Telemecanique 40 x 40 x 70, 70 mm Length, 1 NO Proximity Sensors XS8C2A4DAM12 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | TE INDTIVE PROX SSRS XS |
| Series name | GENERAL PURPOSE |
| Sensor type | INDUCTIVE PROXIMITY SENSOR |
| Sensor name | XS8 |
| Sensor design | Form 40 X 40 X 70 |
| Size | 70 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 2 Wire |
| Discrete output function | 1 NO |
| Detector Flush mounting acceptance | Non Flush Mountable |
| Discrete output type | - |
| Material | Plastic |
| Electrical connection | Male connector M12, 4 pins |
| [Us] rated supply voltage | 12...48 V DC with reverse polarity protection |
| Output circuit type | DC |
| Switching capacity in mA | 1.5...100 mA with overload and short-circuit protection |
| IP degree of protection | IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050 |
| Enclosure material | PBT |
| Detection face | 5 Positions Turret Head |
| Front material | PBT |
| Differential travel | 3 15 PT OF SR |
| Cable composition | - |
| Status LED | Output state: 1 LED (yellow) |
| Wire insulation material | - |
| Switching frequency | <= 200 Hz |
| Voltage drop | <4.2 V (closed) |
| Current consumption | - |
| Delay first up | 7.5000 MILLISECOND |
| Delay response | 1.4000 MILLISECOND |
| Marking | CE |
| Delay recovery | 2.5000 MILLISECOND |
| Product certifications | CCC CSA UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
| Thread type | - |
Obtain a Quote for Telemecanique 40 x 40 x 70, 70 mm Length, 1 NO Proximity Sensors XS8C2A4DAM12 with exclusive offers. Core System Specifications of XS8C2A4DAM12 feature INDUCTIVE PROXIMITY SENSOR, featuring an Form 40 X 40 X 70 design. This sensor operates with an Discrete Type of output signal, 1 NO output, designed for efficient and reliable performance in automation tasks. Rated for 12...48 V DC with reverse polarity protection, ensuring durability in varying power conditions. With a switching capacity up to 1.5...100 mA with overload and short-circuit protection, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an 5 Positions Turret Head detection face and can operate at a switching frequency of up to <= 200 Hz. Initiate Your Journey with a Quote for your requirement of Telemecanique 40 x 40 x 70, 70 mm Length, 1 NO Proximity Sensors. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
