XS7E1A1CAL01M12: Telemecanique 26 x 26 x 13 Proximity Sensors
Technical Specifications of Telemecanique 26 x 26 x 13 Proximity Sensors XS7E1A1CAL01M12:
| Sensor Design | Flat Form 26 X 26 X 13 |
| Wiring Technique | 2 Wire |
| Discrete Output Type | - |
| Electrical Connection | Remote male connector M12, 4 pins |
Telemecanique 26 x 26 x 13 Proximity Sensors XS7E1A1CAL01M12 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | TE INDTIVE PROX SSRS XS |
| Series name | GENERAL PURPOSE |
| Sensor type | INDUCTIVE PROXIMITY SENSOR |
| Sensor name | XS7 |
| Sensor design | Flat Form 26 X 26 X 13 |
| Size | 13 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 2 Wire |
| Discrete output function | 1 NO |
| Detector Flush mounting acceptance | Flush Mountable |
| Discrete output type | - |
| Material | Plastic |
| Electrical connection | Remote male connector M12, 4 pins |
| [Us] rated supply voltage | 12...24 V DC with reverse polarity protection |
| Output circuit type | DC |
| Switching capacity in mA | 1.5...100 mA DC with overload and short-circuit protection |
| IP degree of protection | IP67 double insulation conForming to IEC 60529 |
| Enclosure material | PBT |
| Detection face | Frontal |
| Front material | PBT |
| Differential travel | 1 15 PT OF SR |
| Cable composition | - |
| Status LED | Output state: 1 LED (yellow) |
| Wire insulation material | PVC |
| Switching frequency | <= 1000 Hz |
| Voltage drop | <4 V (closed) |
| Current consumption | - |
| Delay first up | 5.0000 MILLISECOND |
| Delay response | 0.3000 MILLISECOND |
| Marking | CE |
| Delay recovery | 0.7000 MILLISECOND |
| Product certifications | CSA C TICK ECOLAB UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
| Thread type | - |
Please speak to our Technical Engineer for Telemecanique 26 x 26 x 13 Proximity Sensors XS7E1A1CAL01M12 at attractive prices. Technical Specs Summary of XS7E1A1CAL01M12 includes INDUCTIVE PROXIMITY SENSOR, featuring an Flat Form 26 X 26 X 13 design. This sensor operates with an Discrete Type of output signal, 1 NO output, designed for efficient and reliable performance in automation tasks. Rated for 12...24 V DC with reverse polarity protection, ensuring durability in varying power conditions. With a switching capacity up to 1.5...100 mA DC with overload and short-circuit protection, it promises safe and stable operation. Its IP67 double insulation conForming to IEC 60529, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an Frontal detection face and can operate at a switching frequency of up to <= 1000 Hz. Match Your Needs with a Quote for your requirement of Telemecanique 26 x 26 x 13 Proximity Sensors. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
