XS7C4A1DPG13 - Telemecanique 40 x 40 x 117 Proximity Sensors
Technical Specifications of Telemecanique 40 x 40 x 117 Proximity Sensors XS7C4A1DPG13 :
| Brand | Telemecanique |
| Product Type | Proximity Sensor |
| Model Number | XS7C4A1DPG13 |
Telemecanique 40 x 40 x 117 Proximity Sensors XS7C4A1DPG13 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Inductive proximity sensors XS |
| Series name | General Purpose |
| Sensor type | Inductive proximity sensor |
| Sensor name | XS7 |
| Sensor design | Form 40 X 40 X 117 |
| Size | 117 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 2 Wire |
| Discrete output function | 1 NO OR 1 NC Programmable |
| Detector Flush mounting acceptance | Flush Mountable |
| Material | Plastic |
| Electrical connection | Screw-clamp terminals, 4 x 1.5 mm² |
| [Us] rated supply voltage | 12...48 V DC with reverse polarity protection |
| Output circuit type | DC |
| Switching capacity in mA | 1.5...100 mA with overload and short-circuit protection |
| IP degree of protection | IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050 |
| Enclosure material | PBT |
| Detection face | 5 Positions Turret Head |
| Front material | PBT |
| Differential travel | 3 15 PT OF SR |
| Status LED | Output state: 1 LED (yellow) |
| Switching frequency | <= 300 Hz |
| Voltage drop | <4.2 V (closed) |
| Delay first up | 7.5000 MILLISECOND |
| Delay response | 1.2000 MILLISECOND |
| Marking | CE |
| Delay recovery | 1.8000 MILLISECOND |
| Product certifications | CCC CSA UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
Mail Us for Telemecanique 40 x 40 x 117 Proximity Sensors XS7C4A1DPG13 at the lowest pricing. Technical Specs Summary of XS7C4A1DPG13 are Inductive proximity sensor, featuring an Form 40 X 40 X 117 design. This sensor operates with an Discrete Type of output signal, 1 NO OR 1 NC Programmable output, designed for efficient and reliable performance in automation tasks. Rated for 12...48 V DC with reverse polarity protection, ensuring durability in varying power conditions. With a switching capacity up to 1.5...100 mA with overload and short-circuit protection, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP65 conForming to IEC 60529, IP69K conForming to DIN 40050, IP degree of protection makes it suitable for challenging environments. Built from durable PBT, this sensor is designed with an 5 Positions Turret Head detection face and can operate at a switching frequency of up to <= 300 Hz. Take the First Step with a Quote for your requirement of Telemecanique 40 x 40 x 117 Proximity Sensors. Choose us for unparalleled pricing and support over other Dealers & Distributors.
