XS4P08MB230 - Telemecanique XS4 Series Inductive Sensors
Technical Specifications of Telemecanique XS4 Series Inductive Sensors XS4P08MB230 :
| Brand | Telemecanique |
| Product Type | Proximity Sensor |
| Model Number | XS4P08MB230 |
Telemecanique XS4 Series Inductive Sensors XS4P08MB230 Technical Specifications
| Specification | Value |
|---|---|
| Series name | General Purpose |
| Sensor type | Inductive proximity sensor |
| Sensor name | XS4 |
| Sensor design | Cylindrical M8 |
| Size | 50 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 2 Wire |
| Discrete output function | 1 NC |
| Detector Flush mounting acceptance | Non Flush Mountable |
| Material | Plastic |
| Electrical connection | Cable |
| [Us] rated supply voltage | 24...240 V AC/DC 50/60 Hz |
| Output circuit type | AC DC |
| Switching capacity in mA | 5...100 mA AC/DC |
| IP degree of protection | IP67 conForming to IEC 60529 |
| Enclosure material | PPS |
| Detection face | Frontal |
| Front material | PPS |
| Differential travel | 1 15 PT OF SR |
| Cable composition | 2 X 0 11 mm2 |
| Status LED | Output state: 1 LED (yellow) |
| Wire insulation material | PVC |
| Switching frequency | <= 25 Hz AC, <= 3000 Hz DC |
| Voltage drop | <5.5 V (closed) |
| Delay first up | 40.0000 MILLISECOND |
| Delay response | 0.2000 MILLISECOND |
| Marking | CE |
| Delay recovery | 0.2000 MILLISECOND |
| Product certifications | CCC CSA ECOLAB UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
| Thread type | M8 X 1 |
Please speak to our Technical Engineer for Telemecanique XS4 Series Inductive Sensors XS4P08MB230 at attractive prices. Technical Specs Summary of XS4P08MB230 includes Inductive proximity sensor, featuring an Cylindrical M8 design. This sensor operates with an Discrete Type of output signal, 1 NC output, designed for efficient and reliable performance in automation tasks. Rated for 24...240 V AC/DC 50/60 Hz, ensuring durability in varying power conditions. With a switching capacity up to 5...100 mA AC/DC, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP degree of protection makes it suitable for challenging environments. Built from durable PPS, this sensor is designed with an Frontal detection face and can operate at a switching frequency of up to <= 25 Hz AC, <= 3000 Hz DC. Match Your Needs with a Quote for your requirement of Telemecanique XS4 Series Inductive Sensors. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
