XS2M12KP340D: Telemecanique 66 mm Length Proximity Sensors
Technical Specifications of Telemecanique 66 mm Length Proximity Sensors XS2M12KP340D:
| Sensor Design | Cylindrical M12 |
| Wiring Technique | 4 Wire |
| Discrete Output Type | PNP & NPN |
| Electrical Connection | Male connector M12, 4 pins |
Telemecanique 66 mm Length Proximity Sensors XS2M12KP340D Technical Specifications
| Specification | Value |
|---|---|
| Range of product | TE INDTIVE PROX SSRS XS |
| Series name | GENERAL PURPOSE |
| Sensor type | INDUCTIVE PROXIMITY SENSOR |
| Sensor name | XS2 |
| Sensor design | Cylindrical M12 |
| Size | 66 mm |
| Body type | Fixed |
| Type of output signal | Discrete |
| Wiring technique | 4 Wire |
| Discrete output function | 1 NO OR 1 NC Programmable |
| Detector Flush mounting acceptance | Non Flush Mountable |
| Discrete output type | PNP & NPN |
| Material | Metal |
| Electrical connection | Male connector M12, 4 pins |
| [Us] rated supply voltage | 12...24 V DC with reverse polarity protection |
| Output circuit type | DC |
| Switching capacity in mA | <= 200 mA with overload and short-circuit protection |
| IP degree of protection | IP67 conForming to IEC 60529 |
| Enclosure material | Nickel Plated Brass |
| Detection face | Frontal |
| Front material | PPS |
| Differential travel | 1 15 PT OF SR |
| Cable composition | - |
| Status LED | Output state: 1 LED (yellow) |
| Wire insulation material | - |
| Switching frequency | <= 5000 Hz |
| Voltage drop | <2.6 V (closed) |
| Current consumption | 0...10 mA no-load |
| Delay first up | 5.0000 MILLISECOND |
| Delay response | 0.1000 MILLISECOND |
| Marking | CE |
| Delay recovery | 0.1000 MILLISECOND |
| Product certifications | CSA UL |
| Vibration resistance | 25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conForming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conForming to IEC 60068-2-27 |
| Thread type | M12 X 1 |
Please speak to our Technical Engineer for Telemecanique 66 mm Length Proximity Sensors XS2M12KP340D at attractive prices. Technical Specs Summary of XS2M12KP340D includes INDUCTIVE PROXIMITY SENSOR, featuring an Cylindrical M12 design. This sensor operates with an Discrete Type of output signal, 1 NO OR 1 NC Programmable and PNP & NPN output, designed for efficient and reliable performance in automation tasks. Rated for 12...24 V DC with reverse polarity protection, ensuring durability in varying power conditions. With a switching capacity up to <= 200 mA with overload and short-circuit protection, it promises safe and stable operation. Its IP67 conForming to IEC 60529, IP degree of protection makes it suitable for challenging environments. Built from durable Nickel Plated Brass, this sensor is designed with an Frontal detection face and can operate at a switching frequency of up to <= 5000 Hz. Match Your Needs with a Quote for your requirement of Telemecanique 66 mm Length Proximity Sensors. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
