Telemecanique XMPA12B2242 Electromechanical Pressure Sensor

Technical Specifications of Telemecanique Pressure Sensor XMPA12B2242:

Controlled fluid	Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C)
Materials in contact with fluid	Chromated zinc alloy
Pressure sensor name	XMP
IP degree of protection	IP54 conforming to IEC 60529

Telemecanique Electromechanical Pressure Sensor XMPA12B2242 Technical Specifications

Specification	Value
Pressure sensor name	XMP
Fluid connection type	G 3/8 (female) conforming to ISO 228
Controlled fluid	Air (0-70 °C), fresh water (0-70 °C), sea water (0-70 °C)
Cable entry	2 entries incorporating Pg 13.5 plastic cable gland, cable outer diameter: 9-13 mm conforming to NF C 68-300
Contacts type and composition	2 NC snap action
Product specific application	Not applicable
Pressure switch type of operation	Regulation between 2 thresholds
Electrical connection	Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm²
Scale type	Adjustable differential
Setting	Knurled knob and nut
Local display	Without
Electrical circuit type	Power circuit
Materials in contact with fluid	Chromated zinc alloy
Enclosure material	PA impregnated with fibreglass
Operating position	Any position
Pressure actuator	Diaphragm
Terminal block type	4 terminals
Operating rate	10.0000 CYCLE_PER_MINUTE
Terminals description ISO n°1	(3-4)NC
Standards	IEC 60947-4-1
Protective treatment	-
Electrical shock protection class	Class I conforming to IEC 60536
IP degree of protection	IP54 conforming to IEC 60529
Range of product	-
Type of decompression valve	Without
Control type	Without
Resistance across terminals	25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A
Vibration resistance	3 gn conforming to IEC 60068-2-6 (f = 10-500 Hz)
Shock resistance	50 gn conforming to IEC 60068-2-27

Get A Quote for Telemecanique XMPA12B2242 Electromechanical Pressure Sensor at the best price. This sensor is designed with fluid connection G 3/8 (female) conforming to ISO 228 standards, ensuring compatibility with various applications. It features a pressure switch operation type with Regulation between 2 thresholds and an Adjustable differential scale for precision control. It is equipped with 2 NC snap action contacts, Screw-clamp terminals, clamping capacity: minimum : 2 x 4 mm², and 2 entries incorporating Pg 13.5 plastic cable gland, cable outer diameter: 9-13 mm conforming to NF C 68-300 for secure connections. The pressure actuator features a Diaphragm, and the terminal block has 4 terminals for reliable operation. It's Time to get a Quote for your requirement of Telemecanique XMPA12B2242 Electromechanical Pressure Sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
