Telemecanique XE3NP2151: Standard Limit Switches Classic range
Technical Specifications of Telemecanique Standard Limit Switches Classic range XE3NP2151:
| Product or component type | Limit switch contact block |
| Cable entry | - |
| Contacts type and composition | 2 NO + 1 NC |
| Contact operation | Slow-break, break before make |
Telemecanique Standard Limit Switches Classic range XE3NP2151 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Limit switches XC Standard |
| Series name | Standard format |
| Product or component type | Limit switch contact block |
| Device short name | XE3N |
| Body type | - |
| Head type | - |
| Material | - |
| Body material | - |
| Fixing mode | - |
| Movement of operating head | - |
| Type of operator | - |
| Type of approach | - |
| Cable entry | - |
| Contacts type and composition | 2 NO + 1 NC |
| Contact operation | Slow-break, break before make |
| Switch actuation | - |
| Electrical connection | Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm² |
| Contacts insulation form | Zb |
| Positive opening | With |
| Contact code designation | B300, AC-15 (Ue = 240 V), Ie = 1.5 A, Ithe = 6 A conforming to EN/IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to EN/IEC 60947-5-1 appendix A |
| Resistance across terminals | 25 mOhm conforming to IEC 60255-7 category 3 |
| Terminals description ISO n°1 | - |
| Shock resistance | - |
| Vibration resistance | - |
| IP degree of protection | - |
| IK degree of protection | - |
| Electrical shock protection class | - |
| Protective treatment | - |
| Standards | - |
| Product certifications | - |
| Repeat accuracy | - |
| Product specific application | - |
| Head material | - |
| Contact block per direction [control circuit] | - |
| Sensor design | - |
| Overvoltage category | - |
| Product compatibility | XCKD |
| Contacts material | Silver plated contacts |
| Environmental characteristic | - |
| Local display | - |
