Telemecanique XCSPL751: Safety Switches
Technical Specifications of Telemecanique Safety Switches XCSPL751:
| Design | - |
| Electrical Connection | Terminal |
| Head Type | Turret head rotary lever |
| Contact Operation | Slow-break |
Telemecanique Safety Switches XCSPL751 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Safety switches XCS |
| Product or component type | Guard switch |
| Component name | XCSPL |
| Design | - |
| Material | Plastic |
| Head type | Turret head rotary lever |
| Contacts type and composition | 1 NC + 1 NC |
| Contact operation | Slow-break |
| Cable entry | 1 entry tapped for Pg 11 |
| Electrical connection | Terminal |
| Locking options description | - |
| Local signalling | - |
| Positive opening | With NC contact |
| Actuator force for extraction | - |
| Operating rate | - |
| Safety level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
| Safety reliability data | B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Body material | - |
| Head material | - |
| Standards | EN/IEC 60204-1 |
| Product certifications | UL |
| Protective treatment | TC |
| Vibration resistance | 50 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class II conforming to EN/IEC 61140 |
| IP degree of protection | IP67 conforming to IEC 60529 |
| Signalling circuit voltage | - |
| Signalling circuit type | - |
| Protection technology | - |
| Type of operator | Straight lever |
| Clamping connection capacity | 1 x 0.5...2 x 1.5 mm² with or without cable end |
| Switch actuation | - |
| Contact code designation | A300, AC-15 (Ue = 120 V, Ie = 6 A) conforming to EN/IEC 60947-5-1, A300, AC-15 (Ue = 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1 |
| Resistance across terminals | 30 mOhm conforming to EN/IEC 60947-5-4 |
| Repeat accuracy | - |
| Enclosure material | Polyamide PA66 fibre glass impregnated |
| Size | - |
| Cable composition | - |
| [Ue] rated operational voltage | - |
| Switching frequency | - |
| Cable material | - |
| Connector type | - |
| [Us] rated supply voltage | - |
Mail Us for your needs in Telemecanique Safety Switches XCSPL751 with budget-friendly prices. The Main Technical Parameters of XCSPL751 include this Guard switch Product or component type and the XCSPL Component name robust protection and precise operation. Designed with 1 NC + 1 NC and Slow-break contacts, it guarantees safe and efficient functionality in critical environments. The switch features an Plastic body providing durability and resistance to harsh conditions. With an industrial design, it supports a Terminal. It delivers excellent reliability under stress, 50 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 vibration resistance standards, and 50 gn for 11 ms conforming to IEC 60068-2-27 shock resistance standards. Customize Your Experience with a Quote for your requirement of Safety Switches. Experience the difference with our competitive pricing and superior support over other Suppliers.
