Telemecanique XCSMP59L5: Safety Switches
Technical Specifications of Telemecanique Safety Switches XCSMP59L5:
| Design | Miniature |
| Electrical Connection | Pre-cabled |
| Head Type | Key operated fixed head |
| Contact Operation | Slow-break, break before make |
Telemecanique Safety Switches XCSMP59L5 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Safety switches XCS |
| Product or component type | Safety switch |
| Component name | XCSMP |
| Design | Miniature |
| Material | Plastic |
| Head type | Key operated fixed head |
| Contacts type and composition | 1 NC + 1 NO |
| Contact operation | Slow-break, break before make |
| Cable entry | - |
| Electrical connection | Pre-cabled |
| Locking options description | Without locking of actuator |
| Local signalling | - |
| Positive opening | With NC contact |
| Actuator force for extraction | 8.0000 NEWTON |
| Operating rate | 20 cyc/mn for maximum durability |
| Safety level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508 |
| Safety reliability data | B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Body material | PA (polyamide) |
| Head material | PA (polyamide) |
| Standards | EN/IEC 60204-1 |
| Product certifications | CUL |
| Protective treatment | TC |
| Vibration resistance | 6 gn (f= 10-55 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 50 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class II conforming to EN/IEC 61140 |
| IP degree of protection | IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
| Signalling circuit voltage | - |
| Signalling circuit type | - |
| Protection technology | - |
| Type of operator | - |
| Clamping connection capacity | - |
| Switch actuation | - |
| Contact code designation | - |
| Resistance across terminals | - |
| Repeat accuracy | - |
| Enclosure material | - |
| Size | - |
| Cable composition | 4 x 0.5 mmΒ² |
| [Ue] rated operational voltage | - |
| Switching frequency | - |
| Cable material | - |
| Connector type | - |
| [Us] rated supply voltage | - |
Please speak to our Technical Engineer for Telemecanique Safety Switches XCSMP59L5 at attractive prices. Technical Specs Summary of XCSMP59L5 includes Miniature safety applications. This Key operated fixed head type Safety switch Product or component type and the XCSMP Component name robust protection and precise operation. Designed with 1 NC + 1 NO and Slow-break, break before make contacts, it guarantees safe and efficient functionality in critical environments. The switch features an Plastic body and a PA (polyamide) head, providing durability and resistance to harsh conditions. With an industrial design, it supports a Pre-cabled. It delivers excellent reliability under stress, 6 gn (f= 10-55 Hz) conforming to IEC 60068-2-6 vibration resistance standards, and 50 gn for 11 ms conforming to IEC 60068-2-27 shock resistance standards. Match Your Needs with a Quote for your requirement of Safety Switches. We lead with pricing that's more favorable and support that's more attentive than other Suppliers & Traders.
