Telemecanique XCSM3710L1: Safety Switches
Technical Specifications of Telemecanique Safety Switches XCSM3710L1:
| Design | Miniature |
| Electrical Connection | Pre-cabled |
| Head Type | Plunger head |
| Contact Operation | Slow-break, break before make |
Telemecanique Safety Switches XCSM3710L1 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | - |
| Product or component type | Safety limit switch |
| Component name | XCSM |
| Design | Miniature |
| Material | Metal |
| Head type | Plunger head |
| Contacts type and composition | 1 NC + 1 NC + 1 NO |
| Contact operation | Slow-break, break before make |
| Cable entry | - |
| Electrical connection | Pre-cabled |
| Locking options description | - |
| Local signalling | - |
| Positive opening | With NC contact |
| Actuator force for extraction | - |
| Operating rate | - |
| Safety level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
| Safety reliability data | B10d = 50000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Body material | Zamak |
| Head material | Zamak |
| Standards | EN 1088 |
| Product certifications | UL |
| Protective treatment | TC |
| Vibration resistance | 25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 25 gn for 18 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class I conforming to NF C 20-030, class I conforming to EN/IEC 61140 |
| IP degree of protection | IP66 conforming to IEC 60529, IP67 conforming to IEC 60529, IP68 conforming to IEC 60529 |
| Signalling circuit voltage | - |
| Signalling circuit type | - |
| Protection technology | Plastic protective cover, secured by 5-lobe socket head safety screw |
| Type of operator | Metal end plunger |
| Clamping connection capacity | - |
| Switch actuation | - |
| Contact code designation | B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN 60947-5-1, B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to EN/IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN 60947-5-1, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to EN/IEC 60947-5-1 appendix A |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3 |
| Repeat accuracy | 0.05 mm on the tripping points |
| Enclosure material | - |
| Size | - |
| Cable composition | 7 x 0.5 mm² |
| [Ue] rated operational voltage | - |
| Switching frequency | - |
| Cable material | - |
| Connector type | - |
| [Us] rated supply voltage | - |
IndMALL Automation Dealing offers Telemecanique Safety Switches XCSM3710L1 at unbeatable prices. The Main Technical Parameters of XCSM3710L1 are Miniature safety applications. This Plunger head type Safety limit switch Product or component type and the XCSM Component name robust protection and precise operation. Designed with 1 NC + 1 NC + 1 NO and Slow-break, break before make contacts, it guarantees safe and efficient functionality in critical environments. The switch features an Metal body and a Zamak head, providing durability and resistance to harsh conditions. With an industrial design, it supports a Pre-cabled. It delivers excellent reliability under stress, 25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 vibration resistance standards, and 25 gn for 18 ms conforming to IEC 60068-2-27 shock resistance standards. Take the First Step with a Quote for your requirement of Safety Switches. Choose us for unparalleled pricing and support over other Dealers & Distributors.
