Telemecanique XCSLF2525342: Safety Switches

Technical Specifications of Telemecanique Safety Switches XCSLF2525342:

Design	Slim
Electrical Connection	Spring terminal, clamping capacity: 1 x 1.5 mm² flexible or solid cable, spring terminal, clamping capacity: 2 x 0.5 mm² flexible cables with 13 mm bared ends
Head Type	Key operated turret head
Contact Operation	Slow-break, break before make

Telemecanique Safety Switches XCSLF2525342 Technical Specifications

Specification	Value
Range of product	Telemecanique Safety switches XCS
Product or component type	Safety switch
Component name	XCSLF
Design	Slim
Material	Metal
Head type	Key operated turret head
Contacts type and composition	1 NC + 1 NO
Contact operation	Slow-break, break before make
Cable entry	3 entries tapped for M20 x 1.5
Electrical connection	Spring terminal, clamping capacity: 1 x 1.5 mm² flexible or solid cable, spring terminal, clamping capacity: 2 x 0.5 mm² flexible cables with 13 mm bared ends
Locking options description	With interlocking, locking by solenoid
Local signalling	1 LED (orange) for actuator withdrawn, 1 LED (green) for actuator inserted and locked
Positive opening	With NC contact
Actuator force for extraction	20.0000 NEWTON
Operating rate	10 cyc/mn for maximum durability
Safety level	Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 conforming to IEC 61508
Safety reliability data	B10d = 5500000 value given for a life time of 20 years limited by mechanical or contact wear
Body material	Zamak
Head material	Zamak
Standards	IEC 60204-1
Product certifications	UL
Protective treatment	TC
Vibration resistance	5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Shock resistance	10 gn for 11 ms conforming to IEC 60068-2-27
Electrical shock protection class	Class I conforming to IEC 61140
IP degree of protection	IP66 conforming to EN/IEC 60529 and EN/IEC 60947-5-1, IP67
Signalling circuit voltage	230 V
Signalling circuit type	AC
Protection technology	-
Type of operator	-
Clamping connection capacity	-
Switch actuation	-
Contact code designation	-
Resistance across terminals	-
Repeat accuracy	-
Enclosure material	-
Size	-
Cable composition	-
[Ue] rated operational voltage	-
Switching frequency	-
Cable material	-
Connector type	-
[Us] rated supply voltage	230 V - 15...10 %
