Telemecanique XCSA503: Safety Switches
Technical Specifications of Telemecanique Safety Switches XCSA503:
| Design | Industrial |
| Electrical Connection | Terminal, clamping capacity: 1 x 0.5...2 x 1.5 mmΒ² with or without cable end |
| Contacts type and composition | 1 NC + 2 NO |
| IP degree of protection | IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
Telemecanique Safety Switches XCSA503 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | Telemecanique Safety switches XCS |
| Product or component type | Safety switch |
| Component name | XCSA |
| Design | Industrial |
| Material | Metal |
| Head type | Key operated turret head |
| Contacts type and composition | 1 NC + 2 NO |
| Contact operation | Slow-break, break before make |
| Cable entry | 1 entry tapped for 1/2" NPT |
| Electrical connection | Terminal, clamping capacity: 1 x 0.5...2 x 1.5 mmΒ² with or without cable end |
| Locking options description | Without locking of actuator |
| Local signalling | Without |
| Positive opening | With NC contact |
| Actuator force for extraction | 20.0000 NEWTON |
| Operating rate | 10 cyc/mn for maximum durability |
| Safety level | Can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508 |
| Safety reliability data | B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear |
| Body material | Zamak |
| Head material | Zamak |
| Standards | IEC 60204-1 |
| Product certifications | UL |
| Protective treatment | TC |
| Vibration resistance | 5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Shock resistance | 10 gn for 11 ms conforming to IEC 60068-2-27 |
| Electrical shock protection class | Class I conforming to IEC 61140 |
| IP degree of protection | IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1 |
Ask for the Pricing of Telemecanique Safety Switches XCSA503 at unbeatable prices. Detailed Specifications of XCSA503 features Industrial safety applications. This Key operated turret head type Safety switch Product or component type and the XCSA Component name robust protection and precise operation. Designed with 1 NC + 2 NO and Slow-break, break before make contacts, it guarantees safe and efficient functionality in critical environments. The switch features an Metal body and a Zamak head, providing durability and resistance to harsh conditions. With an industrial design, it supports a Terminal, clamping capacity: 1 x 0.5...2 x 1.5 mmΒ² with or without cable end. It delivers excellent reliability under stress, 5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 vibration resistance standards, and 10 gn for 11 ms conforming to IEC 60068-2-27 shock resistance standards. Now's the Time to Secure a Quote for your requirement of Safety Switches. We're committed to offering more favorable pricing and more responsive support than other Traders.
