Telemecanique Sensors XCRE181EX Limit Switch
Technical Specifications of Telemecanique Limit Switch XCRE181EX:
| Product or component type | Limit switch |
| Sensor design | - |
| IP degree of protection | IP65 conforming to IEC 60529 |
| Contacts type and composition | 2 x (1 NC + 1 NO) |
Telemecanique Sensors Limit Switch XCRE181EX Technical Specifications
| Specification | Value |
|---|---|
| Range of product | OsiSense ATEX D |
| Series name | Special format |
| Product or component type | Limit switch |
| Device short name | XCR |
| Sensor design | - |
| Body type | Fixed |
| Head type | Rotary head |
| Material | Metal |
| Fixing mode | By the body |
| Movement of operating head | Rotary |
| Type of operator | Stay put crossed rods lever metal square rod 6 mm |
| Switch actuation | By any moving part |
| Type of approach | Lateral approach, 2 directions |
| Electrical connection | Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mmΒ² |
| Contacts type and composition | 2 x (1 NC + 1 NO) |
| Contacts insulation form | Zb |
| Contact operation | Snap action |
| Positive opening | With |
| IP degree of protection | IP65 conforming to IEC 60529 |
| Body material | - |
| Head material | - |
| Contact code designation | A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to IEC 60947-5-1, A300, AC-15 (Ue = 240 V), Ie = 3 A conforming to IEC 60947-5-1 appendix A, Q300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to IEC 60947-5-1, Q300, DC-13 (Ue = 250 V), Ie = 0.27 A conforming to IEC 60947-5-1 appendix A |
| Resistance across terminals | 25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A |
| Marking | II2 D-Ex tb IIIC T85Β°C Db IP66/67 |
| Shock resistance | 68 gn conforming to IEC 60068-2-27 |
| Vibration resistance | 9 gn (f= 10-500 Hz) conforming to IEC 60068-2-6 |
| Electrical shock protection class | Class I conforming to IEC 60536, class I conforming to NF C 20-030 |
| Protective treatment | TC |
| Dust zone | Zone 21 - 22 |
| Product certifications | IEC-Ex INE 16.0048X |
| Standards | IEC 60079-0 |
| Directives | 2014/34/EU - ATEX directive |
Reach Us by Email for Telemecanique Sensors XCRE181EX Limit Switch at Discounted Rates. This limit switch features Fixed Special format, body design with a Metal Rotary head and a Stay put crossed rods lever metal square rod 6 mm. It operates through a By any moving part with Lateral approach, 2 directions, enabling smooth Rotary movement. The switch is equipped with Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 1.5 mmΒ². It includes 2 x (1 NC + 1 NO) Snap action contacts with Zb insulation. Navigate Your Needs with a Quote for your requirement of Telemecanique XCRE181EX Limit Switch. Our pricing and support are unrivaled, especially when compared to other Competitors.
