Telemecanique Sensors XCKM3906H29EX Limit Switch

Technical Specifications of Telemecanique Limit Switch XCKM3906H29EX:

Product or component type	Limit switch
Sensor design	-
IP degree of protection	IP66 conforming to IEC 60529
Contacts type and composition	2 NC + 1 NO

Telemecanique Sensors Limit Switch XCKM3906H29EX Technical Specifications

Specification	Value
Range of product	-
Series name	Standard format
Product or component type	Limit switch
Device short name	XCKM
Sensor design	-
Body type	Fixed
Head type	Multi-directional head
Material	Metal
Fixing mode	By the body
Movement of operating head	Multi-directional
Type of operator	Spring return cat''s whisker
Switch actuation	By any moving part
Type of approach	Multi-directional approach
Electrical connection	Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm²
Contacts type and composition	2 NC + 1 NO
Contacts insulation form	Zb
Contact operation	Snap action
Positive opening	Without
IP degree of protection	IP66 conforming to IEC 60529
Body material	Zamak
Head material	-
Contact code designation	B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to IEC 60947-5-1, B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1 appendix A
Resistance across terminals	25 MOhm conforming to IEC 60255-7 category 3
Marking	II2 D-Ex tb IIIC T85°C Db IP66/67
Shock resistance	50 gn for 11 ms conforming to IEC 60068-2-27
Vibration resistance	25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Electrical shock protection class	Class I conforming to IEC 61140, class I conforming to NF C 20-030
Protective treatment	TC
Dust zone	Zone 21 - 22
Product certifications	IEC-Ex INE 17.0020X
Standards	IEC 60079-0
Directives	2014/34/EU - ATEX directive

Get A Quote for Telemecanique Sensors XCKM3906H29EX Limit Switch at the best price. This limit switch features Fixed Standard format, body design with a Metal Multi-directional head and a Spring return cat''s whisker. It operates through a By any moving part with Multi-directional approach, enabling smooth Multi-directional movement. The switch is equipped with Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm². It includes 2 NC + 1 NO Snap action contacts with Zb insulation and is built with Zamak body material. It's Time to get a Quote for your requirement of Telemecanique XCKM3906H29EX Limit Switch. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
