Telemecanique Sensors XCKJ3961H29EX Limit Switch

Technical Specifications of Telemecanique Limit Switch XCKJ3961H29EX:

Product or component type	Limit switch
Sensor design	Form B conforming to CENELEC EN 50041
IP degree of protection	IP66 conforming to IEC 60529
Contacts type and composition	2 NC + 1 NO

Telemecanique Sensors Limit Switch XCKJ3961H29EX Technical Specifications

Specification	Value
Range of product	Telemecanique Limit switches XC Standard
Series name	Standard format
Product or component type	Limit switch
Device short name	XCKJ
Sensor design	Form B conforming to CENELEC EN 50041
Body type	Fixed
Head type	Plunger head
Material	Metal
Fixing mode	By the body
Movement of operating head	Linear
Type of operator	Spring return plunger metal
Switch actuation	On end
Type of approach	Vertical approach, 1 direction
Electrical connection	Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm²
Contacts type and composition	2 NC + 1 NO
Contacts insulation form	Zb
Contact operation	Snap action
Positive opening	With
IP degree of protection	IP66 conforming to IEC 60529
Body material	Zamak
Head material	Zamak
Contact code designation	B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to IEC 60947-5-1, B300, AC-15 (Ue = 240 V), Ie = 1.5 A conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1, R300, DC-13 (Ue = 250 V), Ie = 0.1 A conforming to IEC 60947-5-1 appendix A
Resistance across terminals	25 MOhm conforming to IEC 60255-7 category 3
Marking	II2 D-Ex tb IIIC T85°C Db IP66/67
Shock resistance	50 gn for 11 ms conforming to IEC 60068-2-27
Vibration resistance	25 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Electrical shock protection class	Class I conforming to IEC 61140, class I conforming to NF C 20-030
Protective treatment	TC
Dust zone	Zone 21 - 22
Product certifications	IEC-Ex INE 17.0020X
Standards	IEC 60079-0
Directives	2014/34/EU - ATEX directive

Mail Us for Telemecanique Sensors XCKJ3961H29EX Limit Switch at unbeatable prices. This limit switch features Fixed Standard format, body design with a Metal Plunger head and a Spring return plunger metal. It operates through a On end with Vertical approach, 1 direction, enabling smooth Linear movement. The switch is equipped with Screw-clamp terminals, clamping capacity: 1 x 0.34...2 x 0.75 mm². It includes 2 NC + 1 NO Snap action contacts with Zb insulation and is built with durable Zamak material for both the body and head. Elevate Your Project with a Quote for your requirement of Telemecanique XCKJ3961H29EX Limit Switch. Count on us for more economical pricing and more reliable support than other Traders & Suppliers.
