Telemecanique 9016GVG1J10 - Electromechanical Vacuum Switch
Technical Specifications of Telemecanique Vacuum Switch 9016GVG1J10:
| Product or component type | Electromechanical vacuum switch |
| Maximum pressure | 100 psi |
| Materials in contact with fluid | 3M Scotch-Grip 847 rubber and gasket adhesive |
| NEMA degree of protection | NEMA 1 conforming to UL 698 |
Telemecanique Electromechanical Vacuum Switch 9016GVG1J10 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | 9016GVG |
| Product or component type | Electromechanical vacuum switch |
| Device application | Power circuit application |
| Electrical circuit type | Power circuit |
| Factory modification | Not applicable |
| Vacuum switch type of operation | Regulation between two thresholds |
| Scale type | Adjustable |
| Value of setting | 16.5...25 inHg |
| Maximum pressure | 100 psi |
| Local display | Without |
| Fluid connection type | 0.25 inch 18 NPSF conforming to UL 508 |
| Electrical connection | Screw-clamp terminals AWG 22...AWG 12 |
| Cable entry | - |
| Terminal block type | 8 screw terminals |
| Pressure actuator | Diaphragm nitrile (Buna-N) |
| Controlled fluid | Air (-40-250 °F), water (-40-250 °F), hydraulic oil (-40-250 °F), gas (-40-250 °F) |
| Materials in contact with fluid | 3M Scotch-Grip 847 rubber and gasket adhesive |
| Enclosure material | Stamped metal |
| Operating position | Any position |
| Operating rate | 100 cyc/mn |
| Local signalling | - |
| Contacts type and composition | 2 NC, DPST-DB, Form YY, snap action, silver cadmium contacts |
| Setting | Internal |
| Standards | UL 508 |
| Product certifications | UL listed |
| Protective treatment | None |
| Vibration resistance | - |
| Shock resistance | - |
| NEMA degree of protection | NEMA 1 conforming to UL 698 |
Mail Us for Telemecanique 9016GVG1J10 Electromechanical Vacuum Switch at the lowest pricing. The key technical features include its suitability for Power circuit application an Adjustable scale, and a maximum pressure handling capacity of 100 psi. It operates as a vacuum switch with Regulation between two thresholds.
The switch comes with a 0.25 inch 18 NPSF conforming to UL 508 fluid connection, and Screw-clamp terminals AWG 22...AWG 12 Electrical connection. It also features an 8 screw terminals block, a -, and Diaphragm nitrile (Buna-N) Pressure actuator. The operating rate is 100 cyc/mn, and 2 NC, DPST-DB, Form YY, snap action, silver cadmium contacts. Take the First Step with a Quote for your requirement of Telemecanique 9016GVG1J10 Electromechanical Vacuum Switch. Choose us for unparalleled pricing and support over other Dealers & Distributors.
