Telemecanique 9016GAW1Z16 - Electromechanical Vacuum Switch
Technical Specifications of Telemecanique Vacuum Switch 9016GAW1Z16:
| Product or component type | Electromechanical vacuum switch |
| Maximum pressure | 100 psi |
| Materials in contact with fluid | 3M Scotch-Grip 847 rubber and gasket adhesive |
| NEMA degree of protection | NEMA 4/4X/13 conforming to UL 698 |
Telemecanique Electromechanical Vacuum Switch 9016GAW1Z16 Technical Specifications
| Specification | Value |
|---|---|
| Range of product | 9016G |
| Product or component type | Electromechanical vacuum switch |
| Device application | Sensitive control application |
| Electrical circuit type | Control circuit |
| Factory modification | Not applicable |
| Vacuum switch type of operation | Regulation between two thresholds |
| Scale type | Adjustable differential |
| Value of setting | Not applicable |
| Maximum pressure | 100 psi |
| Local display | Without |
| Fluid connection type | 0.50 inch - 14 NPT external with 0.25 inch - 18 NPTF internal conforming to UL 508 |
| Electrical connection | Screw-clamp terminals AWG 22...AWG 12 |
| Cable entry | 0.5 inch NPT conduit entrance |
| Terminal block type | 4 screw terminals |
| Pressure actuator | Diaphragm nitrile (Buna-N) |
| Controlled fluid | Air (-40-250 °F), water (-40-250 °F), hydraulic oil (-40-250 °F), gas (-40-250 °F) |
| Materials in contact with fluid | 3M Scotch-Grip 847 rubber and gasket adhesive |
| Enclosure material | Die cast aluminium alloy 380 |
| Operating position | Any position |
| Operating rate | 120 cyc/mn |
| Local signalling | Without: |
| Contacts type and composition | NC-NO, SPDT, Form Z, snap action, silver nickel contacts |
| Setting | Internal |
| Standards | UL 508 |
| Product certifications | UL listed file E12158 CCN NKPZ and CCN NTHT |
| Protective treatment | None |
| Vibration resistance | 2 gn conforming to IEC 68-2-6 (f = 40-150 Hz) |
| Shock resistance | 50 gn conforming to IEC 58-2-27 |
| NEMA degree of protection | NEMA 4/4X/13 conforming to UL 698 |
Call us for Telemecanique 9016GAW1Z16 Electromechanical Vacuum Switch at the best rates. The key technical features include its suitability for Sensitive control application an Adjustable differential scale, and a maximum pressure handling capacity of 100 psi. It operates as a vacuum switch with Regulation between two thresholds.
The switch comes with a 0.50 inch - 14 NPT external with 0.25 inch - 18 NPTF internal conforming to UL 508 fluid connection, and Screw-clamp terminals AWG 22...AWG 12 Electrical connection. It also features an 4 screw terminals block, a 0.5 inch NPT conduit entrance, and Diaphragm nitrile (Buna-N) Pressure actuator. The operating rate is 120 cyc/mn, and NC-NO, SPDT, Form Z, snap action, silver nickel contacts. Unlock Exclusive Pricing with a Quote for your requirement of Telemecanique 9016GAW1Z16 Electromechanical Vacuum Switch. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
