In most procurement cycles, TELEMECANIQUESENSORS-9007B24 is considered with Schmersal Limit Switch, Telemecanique Limit Switch and Telemecanique Telemecaniquesensors Xckj390541H29Ex, giving decision-makers confidence that they’ve chosen the most dependable component.
Telemecanique 9007B24: Limit Switch Lever
Technical Specifications of Telemecanique Limit Switch 9007B24
| Product or component type | Limit switch lever |
| Movement of operating head | Rotary |
| Type of operator | Cast zinc spring return roller lever length: 2.5-2.5 in - offset: - convertible rollers, 2 on same side |
| Positive opening | Without |
Telemecanique Limit Switch Lever 9007B24 Technical Specifications
| Specification | Value |
|---|---|
| Series name | Severe duty |
| Product or component type | Limit switch lever |
| Device short name | 9007T/FT |
| Movement of operating head | Rotary |
| Type of operator | Cast zinc spring return roller lever length: 2.5-2.5 in - offset: - convertible rollers, 2 on same side |
| Type of roller | 2 steel outside roller (convertible) diameter: 1.38 in - width: 0.25 in |
| Type of approach | Lateral approach |
| Positive opening | Without |
| Switch actuation | By 30° cam |
| Environmental characteristic | Standard environment |
| Range of product | - |
