Siemens 6ES7522-1BL10-0AA0 Programmable Logic Controller
The Siemens 6ES7522-1BL10-0AA0 module provides 32 digital outputs operating at 24 V DC with 0.5 A per channel capability. It groups outputs in sets of eight, offers a response time of 0.1–0.5 ms, and includes a 40-pole push-in front connector. The module measures 25 × 147 × 129 mm, weighs 280 g, and supports panel or DIN rail mounting.
| Brand | Siemens |
| Product Type | Programmable Logic Controller |
| Product | 6ES7522-1BL10-0AA0 |
Siemens 6ES7522-1BL10-0AA0 Programmable Logic Controller - Technical Specifications
| Specification | Value |
|---|---|
| Product Description | SIMATIC S7-1500, digital output module, DQ32xDC 24V/0.5A BA, 32 channels in groups of 8, 4 A per group; the module supports the safety-oriented shutdown of load groups up to SIL2 according to EN IEC 62061:2021 and Category 3 / PL d according to EN ISO 13849-1:2015. delivery incl. front connector push-in |
| Product family | SM 522 digital output modules |
| Product Lifecycle (PLM) | PM300:Active Product |
| PLM Effective Date | 219 / 219 |
| Region Specific PriceGroup / Headquarter Price Group | Show prices |
| Metal Factor | AL : N / ECCN : 9N9999 |
| Net Weight (kg) | 15,40 x 20,40 x 4,00 |
| Packaging Dimension | CM |
| Package size unit of measure | 1 Piece |
The Siemens 6ES7522-1BL10-0AA0 Programmable Logic Controller module is a digital output unit in the SIMATIC S7-1500 series designed for industrial applications. It provides 32 output channels, operates at a rated 24 V DC, and supports 0.5 A current per channel within a compact 25 × 147 × 129 mm housing. This Siemens model is commonly used where reliable signal switching and structured output control are required.
This module supports conveyors, packaging equipment, automated assembly systems, and machinery requiring fast-response digital control. With grouped outputs, push-in connectivity, and stable switching performance, it enables precise actuation of relays, solenoids, and indicators. The defined response time of 0.1–0.5 ms and DIN-rail installation help maintain orderly and efficient wiring layouts in automation panels.
The Siemens 6ES7522-1BL10-0AA0 module delivers consistent output performance with 32 channels, a dependable 24 V DC input range, and 0.5 A switching capacity per channel. This Siemens model is suitable for OEM machinery, factory automation, and distributed control panels requiring long-term operational stability. Its construction aligns with S7-1500 system requirements, supporting reliable industrial control operations across varied automation environments.
