Sick WTT2SLC-2P3292B02 Photoelectric Sensor
The Sick WTT2SLC-2P3292B02 photoelectric sensor provides 50β800 mm sensing range with infrared laser light and background suppression for reliable detection. It uses optical time-of-flight, supports IO-Link, offers IP67 protection, and operates from 10β30 V DC with a 95 ms response time. This compact rectangular device belongs to the WTT series and is part of the wider Sick photoelectric sensor family from Sick.
| Brand | Sick |
| Product Type | Photoelectric Sensors |
| Model Number | WTT2SLC-2P3292B02 |
Sick WTT2SLC-2P3292B02 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression, Optical time-of-flight |
| Dimensions (W x H x D) | 7.7 mm x 27.5 mm x 13.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 50 mm ... 800 mm |
| Sensing range | 50 mm ... 800 mm |
| Type of Light | Infrared light |
| Light source | Laser 3) |
| Light spot size (distance) | Γ 10 mm (300 mm) |
| Wave length | 940 nm |
| Laser class | 1 |
| Adjustment | Single teach-in button, IO-Link |
| Supply voltage UB | 10 V DC ... 30 V DC |
| Ripple | < 5 Vpp |
| Current consumption | 20 mA 3) |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Output current Imax. | β€ 50 mA |
| Response time | Typ. 95 ms |
| Switching frequency | 5 Hz |
| Connection type | PVC Cable with M8 male connector, 4-pin, 90 mm 6) |
| Protection class | III |
| Housing material | Plastic, MABS, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Ambient operating temperature | β25 Β°C ... +50 Β°C |
| Ambient temperature, storage | β40 Β°C ... +75 Β°C |
| Weight | - |
The Sick WTT2SLC-2P3292B02 photoelectric sensor is a compact industrial sensing device designed for precise detection within a 50β800 mm range. It uses infrared laser light, optical time-of-flight measurement, and background suppression to ensure stable operation across varying materials. This model belongs to the Sick WTT series and fits seamlessly into industrial automation where reliable proximity detection is required.
In industrial environments, the Sick WTT2SLC-2P3292B02 photoelectric sensor supports conveyor systems, pick-and-place units, packaging lines, and component presence detection. Its stable switching, IO-Link configuration, and IP67 enclosure enable dependable use in machine assembly areas, light-duty automation, and material handling applications. The rectangular housing and compact dimensions allow easy integration in tight machine layouts.
The Sick WTT2SLC-2P3292B02 photoelectric sensor combines a defined sensing range, infrared laser source, and time-of-flight measurement to deliver consistent industrial performance. Sick ensures stable detection, reliable switching, and robust build quality suitable for long-term operation. For buyers in industrial automation, this model offers dependable proximity sensing with straightforward installation and configuration.
