Sick WTT190L-P2236 Photoelectric Sensor
The Sick WTT190L-P2236 Photoelectric Sensor offers a two-hundred to two-thousand five-hundred millimeter sensing range using visible red laser technology. It features background suppression, a PNP switching output, and a β€ 0.5 ms response time supported by a 1,000 Hz switching frequency. Operating on 10β30 V DC, it includes a 658 nm laser, potentiometer adjustment, IP67 ABS housing, and an M8 connector for compact installation. Explore Sick Sensors, view Sick Photoelectric Sensors, and explore the Sick WTT Series.
| Brand | Sick |
| Product Type | Photoelectric Sensors |
| Model Number | WTT190L-P2236 |
Sick WTT190L-P2236 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression, Optical time-of-flight |
| Dimensions (W x H x D) | 17.6 mm x 46.5 mm x 34.1 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 200 mm ... 2,500 mm |
| Sensing range | 200 mm ... 2,500 mm |
| Type of Light | Visible red light |
| Light source | Laser 3) |
| Light spot size (distance) | Γ 10 mm (2,500 mm) |
| Wave length | 658 nm |
| Laser class | 1 (IEC 60825-1 / CDRH 21 CFR 1040.10 & 1040.1 |
| Adjustment | Potentiometer, 4 turns (2 x) |
| Supply voltage UB | 10 V DC ... 30 V DC |
| Ripple | < 5 Vpp |
| Current consumption | 75 mA 3) |
| Switching output | PNP |
| Switching mode | Light/dark switching |
| Output current Imax. | β€ 100 mA |
| Response time | β€ 0.5 ms |
| Switching frequency | 1,000 Hz 6) |
| Connection type | Male connector M8, 4-pin |
| Protection class | III |
| Housing material | Plastic, ABS |
| Optics material | Plastic, PMMA |
| Enclosure rating | IP67 |
| Ambient operating temperature | β10 Β°C ... +50 Β°C |
| Ambient temperature, storage | β40 Β°C ... +70 Β°C |
| Weight | 25 g |
The Sick WTT190L-P2236 Photoelectric Sensor is a compact rectangular laser-based device designed for precise distance detection in industrial automation. The Sick WTT190L-P2236 delivers a 200β2,500 mm sensing range, uses visible red laser light, and provides a PNP switching output for reliable signal transmission. As part of the WTT series, it operates on 10β30 V DC and uses optical time-of-flight to ensure stable detection across variable surfaces.
This sensor is well-suited for conveyors, packaging machines, material handling, automated inspection, and assembly processes. Its background suppression and 1,000 Hz switching frequency support fast-moving applications requiring consistent object detection. The ABS housing with IP67 protection and M8 connector allows secure mounting in space-limited areas while maintaining electrical and environmental durability.
The Sick WTT190L-P2236 Photoelectric Sensor combines long-range capability, fast response, and robust construction for continuous operation in factory environments. With a 658 nm laser source, β€ 0.5 ms response time, and IP67 enclosure, it ensures dependable performance in demanding automation tasks. Sickβs reliable sensing technology makes it a strong choice for engineers needing accurate and durable photoelectric detection.
