Sick WF80-95B410 Fork Sensor
The WF80-95B410 is a Sick Fork Sensor featuring 80 mm fork width and 95 mm fork depth configuration. This Sick Fork Sensor operates using the optical detection principle with 0.5 mm minimum detectable object, PNP/NPN switching output, 100 mA output current, 40 mA current consumption, dark switching mode, 1-point/2-point/dynamic teach-in adjustment, M8 4-pin connector, IP65 aluminum housing, 40 µs jitter, and reverse polarity and short-circuit protection.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF80-95B410 |
Sick WF80-95B410 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 110 mm x 110 mm |
| Fork width | 80 mm |
| Fork depth | 95 mm |
| Minimum detectable object (MDO) | 0.5 mm |
| Adjustment | Teach-in button, cable (Teach-in, sensitivity, light/dark switching, key lock, Teach-in dynamic) |
| Teach-in mode | 1-point teach-in2-point teach-inTeach-in dynamic |
| Current consumption | 40 mA 1) |
| Switching output | PNP/NPN |
| Switching output (voltage) | PNP: HIGH = UV ≤ 2 V / LOW approx. 0 VNPN: HIGH = approx. UV / LOW ≤ 2 V |
| Switching mode | Dark switching |
| Output current Imax. | 100 mA |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| Enclosure rating | IP65 |
| Weight | Approx. 36 g ... 160 g 1) |
| Housing material | Aluminum |
| Functional principle | Optical detection principle |
| Jitter | 40 µs |
WF80-95B410 Sick Fork Sensor is a fixed-gap optical detection device engineered for accurate part sensing in industrial automation. The Sick WF80-95B410 Fork Sensor provides 80 mm fork width, 95 mm fork depth, 0.5 mm minimum detectable object, and PNP/NPN switching output. It belongs to the WFE series and supports 1-point, 2-point, and dynamic teach-in modes for sensitivity control. With 100 mA maximum output current and IP65 enclosure rating, it ensures stable operation in production environments.
In industrial applications, the WF80-95B410 Sick Fork Sensor is used in conveyors, packaging machines, assembly stations, and automated material handling systems. The defined 95 mm fork depth allows reliable detection of labels, small components, and flat objects passing through the sensing gap. The PNP/NPN output simplifies PLC integration, while the M8 4-pin connector ensures structured wiring. Aluminum housing and integrated circuit protection support consistent switching performance in continuous operations.
The Sick WF80-95B410 Fork Sensor combines mechanical fork precision with optical detection stability for automation tasks in India. With 40 µs jitter, 40 mA current consumption, and reverse polarity protection, the model maintains accurate signal response during high-speed processes. As part of Sick’s fork sensor portfolio, this device supports OEMs, system integrators, and panel builders requiring dependable fixed-gap sensing solutions in industrial production systems.
