Sick WF50-40B41CA71 Fork Sensor
The WF50-40B41CA71 is a Sick Fork Sensor with 50 mm fork width and 42 mm fork depth configuration. As part of the Sick portfolio and categorized under Sick Fork Sensor, this WFE model provides 0.2 mm minimum detectable object, push-pull PNP/NPN switching output, IP65 enclosure rating, less than 30 mA current consumption, 100 mA output current, M8 4-pin connector, aluminum housing, optical detection principle, selectable light/dark switching, teach-in modes, circuit protection, and 40 µs jitter.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF50-40B41CA71 |
Sick WF50-40B41CA71 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 80 mm x 57 mm |
| Fork width | 50 mm |
| Fork depth | 42 mm |
| Minimum detectable object (MDO) | 0.2 mm |
| Adjustment | Teach-in button, cable (Teach-in, sensitivity, light/dark switching, key lock, Teach-in dynamic) |
| Teach-in mode | 1-point teach-in2-point teach-inTeach-in dynamic |
| Current consumption | < 30 mA 1) |
| Switching output | Push-pull: PNP/NPN |
| Switching output (voltage) | Push-pull: PNP/NPN High = UV - < 2 V/Low: ≤ 2 V |
| Switching mode | Light/dark switching |
| Output current Imax. | 100 mA |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| Enclosure rating | IP65 |
| Weight | Approx. 36 g ... 160 g 2) |
| Housing material | Aluminum |
| Functional principle | Optical detection principle |
| Jitter | 40 µs |
The WF50-40B41CA71 Sick Fork Sensor is designed for precise object detection in industrial automation systems. This WF50-40B41CA71 Sick Fork Sensor integrates 50 mm fork width, 42 mm fork depth, 0.2 mm minimum detectable object, and push-pull PNP/NPN switching output to ensure consistent signal performance. It belongs to the WFE series and operates using an optical detection principle with configurable teach-in functions.
In conveyor handling, packaging machines, and automated assembly lines, the defined fork geometry supports accurate part detection and positioning. The selectable light/dark switching and 40 µs jitter help maintain stable output even in high-speed industrial processes.
The WF50-40B41CA71 supports up to 100 mA output current and connects through an M8 4-pin connector. With IP65 enclosure rating, aluminum housing, and integrated circuit protection, this Sick Fork Sensor is suitable for continuous industrial automation environments requiring reliable optical detection.
