Sick WF5-95B410 Fork Sensor
The WF5-95B410 is a Sick Fork Sensor with 5 mm fork width and 95 mm fork depth precision detection capability. As part of the Sick portfolio and categorized under Sick Fork Sensor, this WFE model provides 0.2 mm minimum detectable object, PNP/NPN switching output, IP65 enclosure rating, 20 mA current consumption, 100 mA output current, M8 4-pin connector, aluminum housing, optical detection principle, light/dark switching, multi-mode teach-in, circuit protection, and 40 µs jitter.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF5-95B410 |
Sick WF5-95B410 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 35 mm x 110 mm |
| Fork width | 5 mm |
| Fork depth | 95 mm |
| Minimum detectable object (MDO) | 0.2 mm |
| Adjustment | Teach-in button, cable (Teach-in, sensitivity, light/dark switching, key lock, Teach-in dynamic) |
| Teach-in mode | 1-point teach-in2-point teach-inTeach-in dynamic |
| Current consumption | 20 mA 1) |
| Switching output | PNP/NPN |
| Switching output (voltage) | PNP: HIGH = UV ≤ 2 V / LOW approx. 0 VNPN: HIGH = approx. UV / LOW ≤ 2 V |
| Switching mode | Light/dark switching |
| Output current Imax. | 100 mA |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| Enclosure rating | IP65 |
| Weight | Approx. 36 g ... 160 g 1) |
| Housing material | Aluminum |
| Functional principle | Optical detection principle |
| Jitter | 40 µs |
The WF5-95B410 Sick Fork Sensor is designed for precise object detection within compact industrial automation assemblies. This WF5-95B410 Sick Fork Sensor integrates 5 mm fork width, 95 mm fork depth, 0.2 mm minimum detectable object, and PNP/NPN switching output to support reliable control system interfacing. It belongs to the WFE series and operates using an optical detection principle with selectable light/dark switching.
In conveyor systems, packaging lines, and automated assembly equipment, the defined fork geometry ensures stable part detection and accurate positioning. Teach-in configuration via button or cable allows sensitivity adjustment, while 40 µs jitter supports consistent switching response in dynamic production environments.
The WF5-95B410 connects through an M8 4-pin connector and supports up to 100 mA output current. With IP65 enclosure protection, aluminum housing, and integrated circuit safeguards, this Sick Fork Sensor maintains dependable performance under industrial operating conditions.
