Sick WF225-B4150 Fork Sensor
The WF225-B4150 is a Sick Fork Sensor with 225 mm fork width and 60 mm fork depth for wide material detection. As part of the Sick portfolio and categorized under Sick Fork Sensor, this WFE model supports 0.2 mm minimum detectable object, PNP/NPN switching output, IP65 enclosure rating, 40 mA current consumption, 100 mA output current, M8 4-pin connector, aluminum housing, light/dark switching, optical detection principle, circuit protection, and 17 µs jitter.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF225-B4150 |
Sick WF225-B4150 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 12 mm x 262.5 mm x 80 mm |
| Fork width | 225 mm |
| Fork depth | 60 mm |
| Minimum detectable object (MDO) | 0.2 mm |
| Adjustment | Teach-in button, cable (Teach-in, sensitivity, light/dark switching, key lock, Teach-in dynamic) |
| Teach-in mode | 1-point teach-in2-point teach-inTeach-in dynamic |
| Current consumption | 40 mA |
| Switching output | PNP/NPN |
| Switching output (voltage) | PNP: HIGH = UV ≤ 2 V / LOW approx. 0 VNPN: HIGH = approx. UV / LOW ≤ 2 V |
| Switching mode | Light/dark switching |
| Output current Imax. | 100 mA |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | Output Q short-circuit protectedInterference pulse suppression |
| Enclosure rating | IP65 |
| Weight | Approx. 36 g ... 160 g 2) |
| Housing material | Aluminum |
| Functional principle | Optical detection principle |
| Jitter | 17 µs |
The WF225-B4150 Sick Fork Sensor is engineered for wide fork detection in industrial automation systems. This WF225-B4150 Sick Fork Sensor integrates 225 mm fork width, 60 mm fork depth, 0.2 mm minimum detectable object, and PNP/NPN switching output to ensure stable object sensing. It belongs to the WFE series and operates using an optical detection principle with selectable light/dark switching modes.
In conveyor lines, sheet processing, packaging, and automated assembly, the extended fork width enables consistent detection of wide labels, films, and flat materials. The 17 µs jitter supports responsive switching in dynamic production environments. With IP65 enclosure rating and integrated short-circuit protection, the sensor is suitable for demanding industrial installations.
The WF225-B4150 maintains Sick standards for large-width fork sensing applications. Its aluminum housing supports structural stability, while 40 mA current consumption ensures compatibility with industrial control systems. For applications requiring extended fork geometry and reliable push-pull output configuration, the WF225-B4150 Sick Fork Sensor delivers consistent detection performance.
