Sick WF15-60B410 Fork Sensor
The WF15-60B410 is a Sick Fork Sensor featuring 15 mm fork width and 0.2 mm minimum detectable object capability. As part of the Sick portfolio and categorized under Sick Fork Sensor, this model belongs to the WFE series with 59 mm fork depth, PNP/NPN switching output, IP65 enclosure rating, plus/minus sensitivity adjustment, 20 mA consumption, 100 mA output current, M8 4-pin connector, aluminum housing, protected circuitry, optical detection principle, and 17 µs jitter.
| Brand | Sick |
| Product Type | Fork Sensor |
| Model Number | WF15-60B410 |
Sick WF15-60B410 Fork Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 10 mm x 45 mm x 74 mm |
| Fork width | 15 mm |
| Fork depth | 59 mm |
| Minimum detectable object (MDO) | 0.2 mm |
| Adjustment | Plus/minus button (Sensitivity, light/dark switching, key lock) |
| Current consumption | 20 mA 1) |
| Switching output | PNP/NPN |
| Switching output (voltage) | PNP: HIGH = UV ≤ 2 V / LOW approx. 0 VNPN: HIGH = approx. UV / LOW ≤ 2 V |
| Switching mode | Light/dark switching |
| Output current Imax. | 100 mA |
| Connection type | Male connector M8, 4-pin |
| Circuit protection | UV connections, reverse polarity protectedOutput Q short-circuit protectedInterference pulse suppression |
| Enclosure rating | IP65 |
| Weight | Approx. 36 g ... 160 g 1) |
| Housing material | Aluminum |
| Functional principle | Optical detection principle |
| Jitter | 17 µs |
The WF15-60B410 Sick Fork Sensor is designed for precise object detection in industrial automation systems. This WF15-60B410 Sick Fork Sensor provides 15 mm fork width, 59 mm fork depth, 0.2 mm minimum detectable object, and PNP/NPN switching output for stable performance. It belongs to the WFE series and operates using an optical detection principle with light/dark switching. The model is used in automation environments requiring compact sensing geometry and consistent switching response.
In packaging lines, small conveyor systems, labeling equipment, and assembly stations, the WF15-60B410 ensures reliable detection of thin materials and small components. The 59 mm fork depth supports sensing across extended slots while maintaining compact width. With 17 µs jitter and protected circuitry, the sensor delivers responsive switching in PLC-controlled industrial applications.
The WF15-60B410 within the Sick fork sensor portfolio maintains consistent performance under industrial operating conditions. Its aluminum housing, reverse polarity protection, and interference pulse suppression support long-term reliability. Sick maintains standardized engineering across the WFE series for dependable automation integration. For industrial buyers requiring compact fork dimensions and stable PNP/NPN switching logic, the WF15-60B410 Sick Fork Sensor supports accurate optical detection in production environments.
