Sick TIM361-2134101 LiDAR Sensor
The Sick TIM361-2134101 LiDAR Sensor offers a 0.05 m ... 10 m working range, 9 V DC ... 28 V DC power supply, and 1 x βEthernetβ connection, 4-pin M12 female connector, 1 x connection βPowerβ, 12-pin, M12 male connector, 1 x Micro USB female connector, type B connection. Manufactured by Sick under the LiDAR Sensor category, this model belongs to the LMS Series.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | TIM361-2134101 |
Sick TIM361-2134101 LiDAR Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Application | Outdoor |
| Light source | Infrared (850 nm) |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 270Β° |
| Scanning frequency | 15 Hz |
| Angular resolution | 0.33Β° |
| Heating | - |
| Working range | 0.05 m ... 10 m |
| Scanning range | At 10% remission factor, 8 m |
| Connection type | 1 x βEthernetβ connection, 4-pin M12 female connector, 1 x connection βPowerβ, 12-pin, M12 male connector, 1 x Micro USB female connector, type B |
| Supply voltage | 9 V DC ... 28 V DC |
| Power consumption | Typ. 4 W, 16 W with 4 max. loaded digital outputs |
| Housing | - |
| Housing color | Gray (RAL 7032) |
| Enclosure rating | IP67, applies only when the plastic cover of the βAux interfaceβ is closed (IEC 60529:1989+AMD1:1999+AMD2:2013) |
| Protection class | III (IEC 61140:2016-1) |
| Weight | 250 g, without connecting cables |
| Dimensions (L x W x H) | 60 mm x 60 mm x 86 mm |
| MTBF | > 100 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any |
| Systematic error | Β± 60 mm |
| Statistical error | < 20 mm |
| Ethernet | β , TCP/IP. Function, Service interface, parameterization |
| Serial | - |
| Digital outputs | 3 (NPN, additional 1 x βDevice Readyβ) |
| Optical indicators | 2 LEDs (ON, switching status) |
| Ambient operating temperature | β25 Β°C ... +50 Β°C |
| Storage temperature | β40 Β°C ... +75 Β°C |
The Sick TIM361-2134101 LiDAR Sensor is a high-precision 2D Laser Scanner developed by Sick, a global leader in intelligent sensing and industrial automation solutions. Engineered for outdoor area monitoring, mapping, and object detection, this LiDAR Sensor provides dependable and accurate measurement data even in challenging environmental conditions, making it ideal for industrial, logistics, and mobile automation applications.
The TIM361-2134101 operates on an infrared light source at 850 nm with a wide 270Β° horizontal aperture angle and a scanning frequency of 15 Hz, ensuring smooth and continuous area coverage. It delivers a fine angular resolution of 0.33Β° and a working range from 0.05 m to 10 m, offering reliable detection for almost any object shape. Designed for outdoor environments, it features an IP67-rated housing in gray (RAL 7032), which provides excellent protection against dust and water when the auxiliary interface is closed. The sensor consumes a typical 4 W during operation and supports a 9β28 V DC supply voltage. It includes Ethernet connectivity (TCP/IP) for fast data transmission, along with a 12-pin M12 power connector and Micro USB service interface for easy integration and configuration. The Sick TIM361-2134101 also provides three NPN digital outputs and an additional βDevice Readyβ output for enhanced system diagnostics. Compact in size (60 Γ 60 Γ 86 mm) and lightweight (250 g), it ensures flexible installation across automation systems. With a systematic error of Β±60 mm and statistical error below 20 mm, it guarantees precise detection performance with a MTBF and MTTFD exceeding 100 years, reflecting Sickβs reliability and design excellence.
The Sick TIM361-2134101 LiDAR Sensor is commonly used in vehicle navigation, collision avoidance systems, and industrial perimeter monitoring. Its 2D scanning capability allows mobile robots, cranes, and automated guided vehicles (AGVs) to move safely and efficiently by detecting obstacles in real time. Maintenance engineers prefer this model for its long detection range, low power consumption, and stability in harsh outdoor environments. Its easy Ethernet configuration and fast response make it ideal for logistics centers, port automation, and outdoor safety zones. Built for precision and endurance, the TIM361-2134101 combines compact design with robust sensing performance, ensuring continuous and reliable operation for years. Backed by Sickβs decades of expertise in laser-based sensing, it remains a trusted choice among automation professionals worldwide.
For detailed specifications and setup information on the Sick TIM361-2134101, engineers can refer to the TIM361-2134101 datasheet and TIM361-2134101 manual. Before purchasing, itβs recommended to check the current TIM361-2134101 price through verified distributors for cost planning. Known for accuracy, outdoor durability, and advanced scanning reliability, the Sick 2D Laser Scanner continues to set benchmarks in performance and efficiency. With proven industrial-grade construction and dependable operation, the TIM361-2134101 reflects Sickβs commitment to innovation and quality in LiDAR sensing technology.
