Sick TIM320-1131000 LiDAR Sensor
The Sick TIM320-1131000 LiDAR Sensor provides 270° scanning, 15 Hz frequency, and 4 m indoor detection reliability for automation. This Sick TiM Laser Scanner operates using 850 nm infrared light, supports IP65 enclosure, and connects via an M12 12-pin male connector. Positioned within the Sick LiDAR Sensor range, the TIM320-1131000 Sick TiM Laser Scanner enables stable short-range object detection indoors.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | TIM320-1131000 |
Sick TIM320-1131000 LiDAR Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Application | Indoor |
| Light source | Infrared (850 nm) |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 270° |
| Scanning frequency | 15 Hz |
| Angular resolution | 1° |
| Heating | - |
| Working range | 0.05 m ... 4 m |
| Scanning range | At 10% remission factor, 2 m |
| Connection type | 1 x M12 12-pin male connector (0.8 m) |
| Supply voltage | 9 V DC ... 28 V DC |
| Power consumption | Typ. 4 W, 16 W with 4 max. loaded digital outputs |
| Housing | - |
| Housing color | Light blue (RAL 5012) |
| Enclosure rating | IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
| Protection class | III (IEC 61140:2016-1) |
| Weight | 150 g, without connecting cables |
| Dimensions (L x W x H) | 60 mm x 60 mm x 79 mm |
| MTBF | > 100 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any |
| Systematic error | ± 40 mm |
| Statistical error | 30 mm |
| Ethernet | - |
| Serial | - |
| Digital outputs | 3 (NPN, additional 1 x “Device Ready”) |
| Optical indicators | 2 LEDs (ON, switching status) |
| Ambient operating temperature | –10 °C ... +50 °C |
| Storage temperature | –30 °C ... +70 °C |
The TIM320-1131000 Sick TiM Laser Scanner is an indoor LiDAR Sensor designed for controlled industrial environments. It delivers 270° horizontal scanning, a 15 Hz scanning frequency, and a 0.05 m to 4 m working range for accurate near-field detection. The TIM320-1131000 belongs to the TIM Series and supports reliable sensing tasks in industrial automation systems.
In automation setups, the TIM320-1131000 LiDAR Sensor is commonly used on conveyors, packaging lines, assembly stations, and material flow monitoring points. Its NPN digital outputs and device-ready signal allow consistent PLC integration, while defined angular resolution ensures dependable detection of objects moving within short indoor distances.
The Sick TIM320-1131000 LiDAR Sensor combines long service life, IP65 protection, and stable optical performance for continuous operation. Its compact form factor and consistent detection behavior make it suitable for precision-oriented automation tasks. Backed by Sick LiDAR Sensor engineering standards, the TIM320-1131000 remains a dependable choice for indoor industrial applications.
