Sick TIM310-1030000 LiDAR Sensor
The Sick TIM310-1030000 LiDAR Sensor offers a 0.05 m ... 4 m working range, 9 V DC ... 28 V DC power supply, and 1 x 15-pin D-sub HD male connector (0.9 m) connection. Manufactured by Sick under the LiDAR Sensor category, this model belongs to the LMS Series.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | TIM310-1030000 |
Sick TIM310-1030000 LiDAR Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Application | Indoor |
| Light source | Infrared (850 nm) |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 270Β° |
| Scanning frequency | 15 Hz |
| Angular resolution | 1Β° |
| Heating | - |
| Working range | 0.05 m ... 4 m |
| Scanning range | At 10% remission factor, 2 m |
| Connection type | 1 x 15-pin D-sub HD male connector (0.9 m) |
| Supply voltage | 9 V DC ... 28 V DC |
| Power consumption | Typ. 4 W, 16 W with 4 max. loaded digital outputs |
| Housing | - |
| Housing color | Light blue (RAL 5012) |
| Enclosure rating | IP65 (IEC 60529:1989+AMD1:1999+AMD2:2013) |
| Protection class | III (IEC 61140:2016-1) |
| Weight | 150 g, without connecting cables |
| Dimensions (L x W x H) | 60 mm x 60 mm x 79 mm |
| MTBF | > 100 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any |
| Systematic error | Β± 40 mm |
| Statistical error | 30 mm |
| Ethernet | - |
| Serial | - |
| Digital outputs | 3 (PNP, additional 1 x βDevice Readyβ) |
| Optical indicators | 2 LEDs (ON, switching status) |
| Ambient operating temperature | β10 Β°C ... +50 Β°C |
| Storage temperature | β30 Β°C ... +70 Β°C |
The Sick TIM310-1030000 LiDAR Sensor is a compact and high-performance LiDAR Scanner designed by Sick, a trusted name in industrial automation and sensing technology. Built for reliable indoor measurement and detection, this LiDAR Sensor provides accurate area scanning, making it ideal for use in factory automation, safety monitoring, and robotic navigation applications.
The TIM310-1030000 uses an infrared light source operating at 850 nm and delivers a wide 270Β° horizontal aperture angle for broad coverage. It features a scanning frequency of 15 Hz and a 1Β° angular resolution, ensuring smooth and precise measurement data across its working range of 0.05 m to 4 m. The sensor maintains accurate performance with a systematic error of Β±40 mm and a statistical error of 30 mm, even in complex environments. Its durable light blue (RAL 5012) housing with an IP65-rated enclosure protects against dust and water, allowing dependable use in industrial settings. Designed for easy integration, the unit includes a 15-pin D-sub HD male connector and three PNP digital outputs with an additional βDevice Readyβ signal. The 9β28 V DC power supply supports efficient operation with typical power consumption of 4 W, extending up to 16 W when fully loaded. Weighing just 150 g with compact dimensions of 60 Γ 60 Γ 79 mm, the Sick TIM310-1030000 is engineered for space-saving installation while delivering stable long-term performance with a MTBF and MTTFD of over 100 years.
The Sick TIM310-1030000 LiDAR Sensor is widely used for indoor automation, object detection, and robotic guidance applications where reliability and precision are essential. Its compact form and large scanning angle make it suitable for collision prevention, safety field monitoring, and area mapping in automated machines and small AGVs. Maintenance engineers value this model for its consistent detection capabilities in variable lighting conditions and its easy setup using digital output configuration. The TIM310-1030000 performs exceptionally well in warehouse automation, packaging lines, and mobile robot platforms, ensuring precise detection of objects and smooth machine control. With Sickβs proven engineering quality and robust design, it continues to be one of the most dependable LiDAR solutions for industrial indoor applications.
Engineers and system designers seeking more details on the Sick TIM310-1030000 can review the TIM310-1030000 datasheet and TIM310-1030000 manual for installation, wiring, and configuration instructions. Before finalizing procurement, checking the current TIM310-1030000 price from verified distributors ensures cost-effective planning. Known for accuracy, long lifespan, and compact design, the Sick LiDAR Scanner stands out as a reliable choice for industrial automation projects. The TIM310-1030000 continues to represent Sickβs innovation in delivering efficient and intelligent scanning solutions for modern factory environments.
