Sick Sick WTB16P-1H162120A00 Photoelectric Sensor
| Brand | Sick |
| Product Type | Photoelectric Sensor |
| Model Number | Sick WTB16P-1H162120A00 |
Sick Sick WTB16P-1H162120A00 Photoelectric Sensor โ Technical Specifications
| Specification | Value |
|---|
| Functional principle | Photoelectric proximity sensor |
| Functional principle detail | Background suppression |
| Sensing range min. | 10 mm |
| Sensing range max. | 1,000 mm |
| Light source | PinPoint LED |
| Type of light | Visible red light |
| Shape of light spot | Point-shaped |
| Light spot size (distance) | ร 6 mm (500 mm) |
| Wave length | 635 nm |
| Adjustment | Teach-Turn adjustment, IO-Link |
| Indication | LED blue, LED green, LED yellow |
| Supply voltage UB | 10 V DC ... 30 V DC 1) |
| Ripple | โค 5 Vpp |
| Usage category | DC-12 (According to EN 60947-5-2), DC-13 (According to EN 60947-5-2) |
| Current consumption, sender & Receiver | โค 30 mA, without load. At UB = 24 V |
| Protection class | III |
| Digital output Number | 2 (Complementary) |
| Output type | Push-pull: PNP/NPN |
| Signal voltage PNP HIGH/LOW | Approx. UB-2.5 V / 0 V |
| Signal voltage NPN HIGH/LOW | Approx. UB / < 2.5 V |
| Output current Imax. | โค 100 mA |
| Circuit protection outputs | Reverse polarity protected, Overcurrent and short-circuit protected |
| Response time | โค 500 ยตs 2) |
| Repeatability (response time) | 150 ยตs |
| Switching frequency | 1,000 Hz 3) |
| Housing | Rectangular |
| Dimensions (W x H x D) | 20 mm x 55.7 mm x 42 mm |
| Connection | Cable, 4-wire, 2 m |
| Housing material | Plastic, VISTALยฎ |
| Front screen material | Plastic, PMMA |
| Male connector material | - |
| Maximum tightening torque of the fixing screws | 1.3 Nm |
| Enclosure rating | IP66 (EN 60529), IP67 (EN 60529), IP69 (EN 60529) 1) |
| Ambient operating temperature | โ40 ยฐC ... +60 ยฐC |
| Ambient temperature, storage | โ40 ยฐC ... +75 ยฐC |
| Weight | Approx. 100 g |
