Sick S10B-9011DA LiDAR Sensor
The Sick S10B-9011DA LiDAR Sensor provides 270° scanning, 10 m working range, and 30 V DC supply for indoor automation applications systems. This Sick LiDAR Sensor operates using 905 nm infrared light, complies with Class 1 laser safety standards, and supports RS-232 communication with five digital outputs. Positioned within the Sick LiDAR Sensor portfolio, the S10B-9011DA Sick 30V LiDAR Sensor enables reliable short-range object detection.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | S10B-9011DA |
Sick S10B-9011DA LiDAR Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Application | Indoor |
| Light source | Infrared (905 nm) |
| Laser class | 1, complies with 21 CFR 1040.10 and 1040.11 except for the conformance according to “Laser Notice No. 50” from June 24, 2007 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 270° |
| Scanning frequency | 25 Hz |
| Angular resolution | 0.5°, 1° |
| Heating | - |
| Working range | 0 m ... 10 m |
| Scanning range | At 10% remission factor, 4.5 m |
| Connection type | 1 x system plug with screw terminal block (accessory) |
| Supply voltage | 16.8 V DC ... 30 V DC |
| Power consumption | 8 W |
| Housing | - |
| Housing color | Black (RAL 9005) |
| Enclosure rating | IP65 (EN 60529, Section 14.2.5) |
| Protection class | II (VDE 0106, EN50178) |
| Weight | 1.2 kg, without connecting cables |
| Dimensions (L x W x H) | 105 mm x 102 mm x 152 mm |
| MTBF | > 100 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any (diameter: 30 mm, 40 mm, 50 mm, 70 mm, 150 mm (selectable)) |
| Systematic error | - |
| Statistical error | - |
| Ethernet | - |
| Serial | ✔ , RS-232 |
| Digital outputs | 5 (Q1, Q2, Ǭ1, Ǭ2, diagnosis) |
| Optical indicators | 1 7-segment display (contamination warning, initial condition) |
| Ambient operating temperature | –10 °C ... +50 °C |
| Storage temperature | –30 °C ... +70 °C |
The S10B-9011DA Sick 30V LiDAR Sensor is an indoor LiDAR Sensor designed for short-distance monitoring in industrial automation environments. It offers 270° horizontal aperture, 25 Hz scanning frequency, and a defined 0–10 m working range for consistent area coverage. The S10B-9011DA belongs to the S10 Series and is commonly used where simple detection logic and stable output signals are required.
In practical applications, the S10B-9011DA LiDAR Sensor is used in conveyor systems, packaging equipment, assembly lines, and access monitoring zones. The wide scanning angle allows continuous object detection across fixed areas, while selectable object diameters improve detection reliability. RS-232 serial communication and multiple digital outputs enable straightforward integration with PLC-based industrial control systems.
The Sick S10B-9011DA LiDAR Sensor is built for dependable indoor operation with IP65 enclosure protection and defined operating temperature limits. With low power consumption, clear optical status indication, and proven Sick manufacturing reliability, the S10B-9011DA supports long-term industrial use. Sick LiDAR Sensor technology ensures stable performance for basic detection and automation tasks.
