Sick NAV350-3232 LiDAR Sensor
The Sick NAV350-3232 LiDAR Sensor provides 360Β° scanning with 250 m working range for precise indoor navigation applications. This Sick LiDAR Sensor uses 905 nm laser light, supports Class 1 laser safety, and delivers stable detection via Ethernet TCP/IP and RS-232 interfaces. Part of the Sick LiDAR Sensor lineup, the NAV350-3232 Sick 250m LiDAR Sensor is engineered for long-distance indoor localization.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | NAV350-3232 |
Sick NAV350-3232 LiDAR Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Application | Indoor |
| Light source | 905 nm |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 360Β° |
| Scanning frequency | 8 Hz, Β± 5 % |
| Angular resolution | 0.25Β° |
| Heating | - |
| Working range | 0.5 m ... 250 m (0.5 m ... 70 m on reflectors) |
| Scanning range | At 10% remission factor, 35 m. At 90% remission factor, 100 m. |
| Connection type | 3 x M12 male connector/female connector |
| Supply voltage | 24 V DC, Β± 15 % |
| Power consumption | 36 W |
| Housing | Aluminum die cast |
| Housing color | Light blue (RAL 5012) |
| Enclosure rating | IP65 |
| Protection class | III |
| Weight | 2.4 kg |
| Dimensions (L x W x H) | 115 mm x 120.5 mm x 222 mm |
| MTBF | 86 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any |
| Systematic error | Β± 10 mm (RDI), Β± 15 mm (Contour) |
| Statistical error | 15 mm (Contour) |
| Ethernet | β , TCP/IP. Data transmission rate, 100 Mbit/s |
| Serial | β , RS-232. Data transmission rate, 19.2 kBaud ... 115 kBaud |
| Digital outputs | 1 (digital) |
| Optical indicators | 4 LEDs (status displays) |
| Ambient operating temperature | 0 Β°C ... +50 Β°C |
| Storage temperature | β20 Β°C ... +80 Β°C |
The NAV350-3232 Sick 250m LiDAR Sensor is a LiDAR Sensor designed for indoor industrial automation requiring full circular environment scanning. This model supports 0.5 m to 250 m working range, 360Β° horizontal aperture, and 0.25Β° angular resolution for accurate navigation and localization. Operating with a Class 1 laser at 905 nm, it belongs to the NAV Series and is commonly used in guided vehicle and positioning systems.
In industrial environments, the NAV350-3232 LiDAR Sensor is used for automated guided vehicles, mobile robots, conveyor alignment, and warehouse navigation. Full 360Β° scanning enables continuous environment mapping, while long-range detection improves path planning and collision avoidance. Ethernet and serial communication allow seamless integration into control systems, ensuring reliable position feedback and stable data transmission during operation.
The Sick NAV350-3232 LiDAR Sensor combines long service life, consistent measurement accuracy, and industrial-grade housing for dependable indoor use. With IP65 protection, aluminum die-cast construction, and defined error tolerances, the NAV350-3232 supports continuous operation in demanding automation systems. Sick manufacturing standards and established LiDAR expertise ensure this sensor remains suitable for long-term industrial navigation and positioning applications.
