Sick MM08-60ANS-ZUK Proximity Sensor
The Sick MM08-60ANS-ZUK Magnetic Sensor offers a Metric; Short-body, 0 mm ... 70 mm sensing range, 32 mm thread length, PNP NC output, and Cable, 3-wire, 2 m connection. Manufactured by Sick under the Sick Magnetic Sensor category, this model belongs to the MQ Series.
| Brand | Sick |
| Product Type | Magnetic Sensor |
| Model Number | MM08-60ANS-ZUK |
Sick MM08-60ANS-ZUK Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Housing | Metric; Short-body |
| Sensing range Sn | 0 mm ... 70 mm |
| Safe sensing range Sa | 56.7 mm |
| Magnetic sensitivity | β€ 0.7 mT |
| Switching frequency | 5,000 Hz |
| Connection type | Cable, 3-wire, 2 m |
| Switching output | PNP |
| Output function | NC |
| Electrical wiring | DC 3-wire |
| Enclosure rating | IP67 2) |
| Supply voltage | 10 V DC ... 30 V DC |
| Ripple | β€ 10 % 1) |
| Voltage drop | β€ 2 V 2) |
| Current consumption | 10 mA 3) |
| Time delay before availability | β€ 20 ms |
| Hysteresis | 1 % ... 10 % |
| Reproducibility | β€ 1 % 4) |
| Temperature drift (of Sr) | Β± 10 % |
| Continuous current Ia | β€ 200 mA |
| Cable material | PUR |
| Shock and vibration resistance | 30 g, 11 ms / 10 ... 55 Hz, 1 mm |
| Ambient operating temperature | β25 Β°C ... +75 Β°C |
| Housing material | Stainless steel, V4A |
| Thread size | M18 x 1 |
| Diameter | Γ 18 mm |
| Magnetic alignment | Axial |
| Items supplied | Mounting nut, brass, nickel-plated (2x) |
| Housing length | 50 mm |
| Thread length | 32 mm |
| Tightening torque, max. | 40 Nm |
Get A Quote for Sick Normally Closed Magnetic Sensors MM08-60ANS-ZUK part no: 1040066 at the best price. Here are the brief Technical Specifications of MM08-60ANS-ZUK, 1040066 are Metric; Short-body Housing that ensures durability and adaptability in diverse environments. With a Sensing range Sn of 0 mm ... 70 mm it provides accurate detection capabilities. The Switching frequency is an impressive 5,000 Hz allowing for fast and responsive operation. The Connection type is a Cable, 3-wire, 2 m in length, providing easy and flexible installation. The sensor uses a PNP Switching output with DC 3-wire Electrical wiring, operating on a Supply voltage of 10 V DC ... 30 V DC. The Voltage drop is minimal at β€ 2 V 2) and the Current consumption is just 10 mA 3) ensuring energy efficiency. The Housing material is made of robust Metal, Nickel-plated brass and the Thread size is M18 x 1. It's Time to get a Quote for your requirement of Sick Normally Closed Magnetic Sensors. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
