Sick LMS111-10100S09 LiDAR Sensor
The Sick LMS111-10100S09 LiDAR Sensor provides 270Β° scanning, 25β50 Hz frequency, and 20 m outdoor detection range capability applications. This Sick LiDAR Sensor uses infrared 905 nm light, supports IP67 enclosure, integrated heating, and Ethernet TCP/IP with RS-232 communication. Positioned within the Sick LiDAR Sensor portfolio, the LMS111-10100S09 Sick 2D LiDAR Scanner supports reliable object detection for industrial automation.
| Brand | Sick |
| Product Type | Lidar Sensor |
| Model Number | LMS111-10100S09 |
Sick LMS111-10100S09 LiDAR Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Application | Outdoor |
| Light source | Infrared (905 nm) |
| Laser class | 1 (IEC 60825-1:2014, EN 60825-1:2014) |
| Aperture angle | Horizontal, 270Β° |
| Scanning frequency | 25 Hz, 50 Hz |
| Angular resolution | 0.25Β°, 0.5Β° |
| Heating | Yes |
| Working range | 0.5 m ... 20 m |
| Scanning range | At 10% remission factor, 18 m. At 90% remission factor, 20 m. |
| Connection type | 1 x M12 round connector |
| Supply voltage | 10.8 V DC ... 30 V DC |
| Power consumption | Typ. 8 W, heating typ. 35 W |
| Housing | - |
| Housing color | Gray (RAL 7032) |
| Enclosure rating | IP67 (EN 60529, Section 14.2.7) |
| Protection class | III (EN 50178 (1997;10)) |
| Weight | 1.1 kg |
| Dimensions (L x W x H) | 105 mm x 102 mm x 162 mm |
| MTBF | > 100 years |
| MTTFD | > 100 years |
| Detectable object shape | Almost any |
| Systematic error | Β± 30 mm |
| Statistical error | 12 mm |
| Ethernet | β , TCP/IP. Function, Data interface (read result output). Data transmission rate, 10/100 MBit/s. |
| Serial | β , RS-232. Function, Data interface (read result output), Service interface. Data transmission rate, 9.6 kBaud ... 115.2 kBaud. |
| Digital outputs | 3 |
| Optical indicators | 7-segment display (plus 5 LEDs showing device status, contamination warning and initial condition) |
| Ambient operating temperature | β30 Β°C ... +50 Β°C |
| Storage temperature | β30 Β°C ... +70 Β°C |
The LMS111-10100S09 Sick 2D LiDAR Scanner is a LiDAR Sensor designed for outdoor industrial automation environments. This model supports 0.5 m to 20 m working range, 25 Hz and 50 Hz scanning frequency, and a 270Β° horizontal aperture angle. Operating with infrared 905 nm light and Laser Class 1 compliance, it belongs to the LMS Series and is used for consistent area monitoring.
In industrial applications, the LMS111-10100S09 LiDAR Sensor is used for conveyor monitoring, packaging lines, material handling systems, and automated assembly operations. The wide scanning angle enables detection of almost any object shape, while defined angular resolution ensures stable and repeatable output. Integrated heating allows reliable operation in outdoor environments with temperature variation.
The Sick LMS111-10100S09 LiDAR Sensor combines long service life, controlled measurement accuracy, and industrial communication interfaces for dependable automation integration. Ethernet TCP/IP and RS-232 connectivity support straightforward system communication, while three digital outputs enable control logic interfacing. With IP67 protection and outdoor-rated performance, the LMS111-10100S09 is suitable for continuous industrial LiDAR sensing applications.
