Sick KTX-WB9124225AZZZZ Contrast Sensor
Sick KTX-WB9124225AZZZZ Sick ≤ 25 mm Sensing Distance Contrast Sensor ensures reliable detection with 10 µs response time. The KTX-WB9124225AZZZZ operates with 10.8–28.8 V DC supply voltage, push-pull PNP/NPN switching output, IP67 enclosure rating, and 1.2 mm x 5.3 mm vertical light spot with ±6 mm sensing tolerance. As part of the KT series, this Sick Contrast Sensor from Sick supports structured industrial automation applications in India.
| Brand | Sick |
| Product Type | Contrast Sensor |
| Product | KTX-WB9124225AZZZZ |
Sick KTX-WB9124225AZZZZ Contrast Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Dimensions (W x H x D) | 30 mm x 53 mm x 78.5 mm |
| Sensing distance | ≤ 25 mm |
| Sensing distance tolerance | ± 6 mm |
| Housing design | Large |
| Light source | LED, RGB |
| Wave length | 470 nm, 525 nm, 625 nm |
| Light spot size | 1.2 mm x 5.3 mm |
| Light spot direction | Vertical 2) |
| Adjustment | - |
| Supply voltage | 10.8 V DC ... 28.8 V DC |
| Response time | 10 µs 6) 7) |
| Switching output | Push-pull: PNP/NPN |
| Switching mode | - |
| Enclosure rating | IP67 |
| Connection type | Male connector M12, 5-pin |
| Ambient operating temperature | –20 °C ... +60 °C |
KTX-WB9124225AZZZZ Sick ≤ 25 mm Sensing Distance Contrast Sensor is designed for controlled contrast detection in industrial automation. The KTX-WB9124225AZZZZ provides ≤25 mm sensing distance, 10 µs response time, and 10.8–28.8 V DC supply voltage with push-pull PNP/NPN switching output. It belongs to the KT series and is applied where stable optical recognition of marks and labels is required.
This Sick contrast sensor is commonly used in packaging lines, conveyor systems, printing alignment processes, and automated assembly equipment. The RGB LED light source with vertical light spot direction enables consistent performance across varying surface colors and materials. Its large housing design and IP67 enclosure rating allow reliable installation in industrial environments.
KTX-WB9124225AZZZZ from Sick operates within –20 °C to +60 °C and integrates through an M12 5-pin connector for panel wiring. As part of the KT series, this contrast sensor delivers dependable switching behavior and repeatable detection in continuous production systems.
