Home Brands Sick Contrast Sensors KTS-WS41141142ZZZZ Sick KTS-WS41141142ZZZZ Contrast Sensor The Sick KTS-WS41141142ZZZZ Contrast Sensor offers Middle, design ≤ 13 mm sensing distance , 10.8 V DC ... 28.8 V DC supply voltage, PNP, NPN Output Male connector M12, 4-pin connection . Manufactured by Sick under the Sick Contrast Sensor category, this model belongs to the KT Series.
Brand Sick Product Type Contrast Sensor Model Number KTS-WS41141142ZZZZ
Sick KTS-WS41141142ZZZZ Contrast Sensor – Technical Specifications Specification Value Dimensions (W x H x D) 26 mm x 62 mm x 47.5 mm Sensing distance ≤ 13 mm Sensing distance tolerance ± 3 mm Housing design Middle Light source LED, RGB Wave length 470 nm, 525 nm, 625 nm Light emission Long side of housing Light spot size 1.2 mm x 3.9 mm Light spot direction Vertical Teach-in mode 2-point teach-in Supply voltage 10.8 V DC ... 28.8 V DC Ripple ≤ 5 Vpp Current consumption < 100 mA 3) Switching frequency 25 kHz 4) Response time 20 µs 5) Jitter 10 µs Switching output PNP, NPN Switching output (voltage) PNP: HIGH = VS - 3 V / LOW = 0 V, NPN: HIGH = VS / LOW ≤ 3 V Output current Imax. 100 mA 6) Retention time (ET) 35 ms, non-volatile memory Connection type Male connector M12, 4-pin Protection class III Enclosure rating IP67 Weight 68 g Housing material VISTAL® Optics material COP Ambient operating temperature –20 °C ... +60 °C Ambient temperature, storage –25 °C ... +75 °C
